| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58147cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58147cztM0_level2_quad_clean.evt |
| Size (bytes) | 767,802,240 | 85,504,320 |
| Size | 732.2 MB | 81.5 MB |
| Events in quadrant A | 3,094,443 | 664,788 |
| Events in quadrant B | 12,955,634 | 281,062 |
| Events in quadrant C | 3,104,397 | 630,028 |
| Events in quadrant D | 8,756,943 | 553,594 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13692 | 2 |
| B | 0 | 43094 | 2 |
| C | 0 | 13875 | 2 |
| D | 0 | 30625 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6589 | 103 | 1.563211% |
| B | 6589 | 4208 | 63.864016% |
| C | 6589 | 76 | 1.153438% |
| D | 6588 | 623 | 9.456588% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7639 | 6589 | 8 | 8 | 0.10% | 0.12% |  |
| B | 7638 | 6588 | 3669 | 3669 | 48.04% | 55.69% |  |
| C | 7639 | 6589 | 5 | 5 | 0.07% | 0.08% |  |
| D | 7638 | 6588 | 545 | 545 | 7.14% | 8.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 3 | 90028 | 478.33 | 761 | 744 | 186.7 |
| A | 3 | 245 | 47454 | 250.24 | 761 | 744 | 186.7 |
| A | 3 | 14 | 11630 | 58.32 | 761 | 744 | 186.7 |
| B | 10 | 128 | 10301871 | 101053.06 | 472 | 453 | 101.9 |
| B | 5 | 185 | 383730 | 3759.8 | 472 | 453 | 101.9 |
| B | 4 | 201 | 163028 | 1594.8 | 472 | 453 | 101.9 |
| C | 12 | 252 | 108612 | 534.94 | 739 | 734 | 201.7 |
| C | 6 | 223 | 34283 | 166.36 | 739 | 734 | 201.7 |
| C | 14 | 254 | 31928 | 154.68 | 739 | 734 | 201.7 |
| D | 12 | 110 | 4595221 | 22888.16 | 709 | 677 | 200.7 |
| D | 8 | 160 | 1042125 | 5188.07 | 709 | 677 | 200.7 |
| D | 2 | 249 | 141112 | 699.59 | 709 | 677 | 200.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
