| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58149cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58149cztM0_level2_quad_clean.evt |
| Size (bytes) | 787,944,960 | 79,038,720 |
| Size | 751.4 MB | 75.4 MB |
| Events in quadrant A | 3,005,664 | 677,446 |
| Events in quadrant B | 13,766,950 | 221,526 |
| Events in quadrant C | 3,179,728 | 638,533 |
| Events in quadrant D | 8,714,650 | 406,138 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13263 | 2 |
| B | 0 | 45421 | 2 |
| C | 0 | 13805 | 2 |
| D | 0 | 30185 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6440 | 101 | 1.568323% |
| B | 6440 | 4782 | 74.254658% |
| C | 6440 | 98 | 1.521739% |
| D | 6440 | 2301 | 35.729814% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7600 | 6440 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7599 | 6439 | 4248 | 4248 | 55.90% | 65.97% |  |
| C | 7600 | 6440 | 9 | 9 | 0.12% | 0.14% |  |
| D | 7600 | 6440 | 2064 | 2064 | 27.16% | 32.05% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 3 | 19230 | 97.72 | 769 | 749 | 189.1 |
| A | 2 | 143 | 9864 | 48.2 | 769 | 749 | 189.1 |
| A | 3 | 137 | 9162 | 44.49 | 769 | 749 | 189.1 |
| B | 10 | 128 | 11711701 | 122173.24 | 442 | 426 | 95.9 |
| B | 0 | 79 | 62661 | 649.24 | 442 | 426 | 95.9 |
| B | 5 | 185 | 48434 | 500.82 | 442 | 426 | 95.9 |
| C | 12 | 252 | 166736 | 824.91 | 739 | 733 | 201.2 |
| C | 6 | 223 | 46209 | 225.98 | 739 | 733 | 201.2 |
| C | 9 | 38 | 33802 | 164.33 | 739 | 733 | 201.2 |
| D | 12 | 110 | 5707722 | 31986.91 | 633 | 605 | 178.4 |
| D | 2 | 249 | 90375 | 503.14 | 633 | 605 | 178.4 |
| D | 8 | 240 | 83972 | 467.25 | 633 | 605 | 178.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
