| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58173cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58173cztM0_level2_quad_clean.evt |
| Size (bytes) | 736,657,920 | 73,359,360 |
| Size | 702.5 MB | 70.0 MB |
| Events in quadrant A | 2,648,437 | 578,197 |
| Events in quadrant B | 12,735,202 | 216,196 |
| Events in quadrant C | 2,943,668 | 545,821 |
| Events in quadrant D | 8,467,424 | 453,461 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12403 | 1 |
| B | 0 | 42070 | 1 |
| C | 0 | 13344 | 1 |
| D | 0 | 29448 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6113 | 28 | 0.458040% |
| B | 6114 | 4401 | 71.982336% |
| C | 6114 | 59 | 0.964998% |
| D | 6114 | 915 | 14.965653% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6928 | 6114 | 1 | 1 | 0.01% | 0.02% |  |
| B | 6929 | 6115 | 3802 | 3802 | 54.87% | 62.17% |  |
| C | 6929 | 6115 | 41 | 41 | 0.59% | 0.67% |  |
| D | 6929 | 6115 | 927 | 927 | 13.38% | 15.16% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 28868 | 171.82 | 666 | 650 | 164.2 |
| A | 4 | 3 | 13634 | 79.06 | 666 | 650 | 164.2 |
| A | 2 | 79 | 13628 | 79.02 | 666 | 650 | 164.2 |
| B | 10 | 128 | 10786386 | 112233.85 | 447 | 431 | 96.1 |
| B | 0 | 79 | 45388 | 467.8 | 447 | 431 | 96.1 |
| B | 5 | 185 | 41821 | 430.69 | 447 | 431 | 96.1 |
| C | 6 | 223 | 215045 | 1216.42 | 644 | 637 | 176.3 |
| C | 14 | 254 | 81047 | 456.2 | 644 | 637 | 176.3 |
| C | 14 | 245 | 48529 | 271.71 | 644 | 637 | 176.3 |
| D | 12 | 110 | 4778313 | 28160.92 | 601 | 574 | 169.7 |
| D | 12 | 128 | 601923 | 3544.47 | 601 | 574 | 169.7 |
| D | 8 | 240 | 262673 | 1544.86 | 601 | 574 | 169.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
