| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58192cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58192cztM0_level2_quad_clean.evt |
| Size (bytes) | 432,887,040 | 100,175,040 |
| Size | 412.8 MB | 95.5 MB |
| Events in quadrant A | 3,105,965 | 670,329 |
| Events in quadrant B | 3,895,332 | 711,937 |
| Events in quadrant C | 3,007,268 | 641,925 |
| Events in quadrant D | 5,510,105 | 555,817 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13567 | 2 |
| B | 0 | 15797 | 2 |
| C | 0 | 13464 | 2 |
| D | 0 | 20703 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6497 | 142 | 2.185624% |
| B | 6497 | 261 | 4.017239% |
| C | 6497 | 111 | 1.708481% |
| D | 6497 | 633 | 9.742958% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7612 | 6498 | 8 | 8 | 0.11% | 0.12% |  |
| B | 7612 | 6497 | 42 | 42 | 0.55% | 0.65% |  |
| C | 7612 | 6497 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7612 | 6498 | 485 | 485 | 6.37% | 7.46% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 245 | 45001 | 233.3 | 774 | 754 | 189.7 |
| A | 6 | 226 | 24380 | 124.57 | 774 | 754 | 189.7 |
| A | 4 | 3 | 22767 | 116.07 | 774 | 754 | 189.7 |
| B | 10 | 128 | 494261 | 3086.73 | 750 | 723 | 159.9 |
| B | 0 | 79 | 97731 | 606.72 | 750 | 723 | 159.9 |
| B | 4 | 201 | 96967 | 601.94 | 750 | 723 | 159.9 |
| C | 6 | 223 | 33415 | 157.61 | 755 | 746 | 207.3 |
| C | 12 | 252 | 16728 | 77.1 | 755 | 746 | 207.3 |
| C | 6 | 9 | 8379 | 36.82 | 755 | 746 | 207.3 |
| D | 8 | 160 | 1061517 | 5263.41 | 719 | 688 | 201.5 |
| D | 1 | 3 | 557833 | 2764.33 | 719 | 688 | 201.5 |
| D | 6 | 239 | 213736 | 1057.06 | 719 | 688 | 201.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
