| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58211cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58211cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,358,080 | 102,576,960 |
| Size | 569.7 MB | 97.8 MB |
| Events in quadrant A | 3,557,910 | 705,093 |
| Events in quadrant B | 7,113,787 | 657,535 |
| Events in quadrant C | 3,498,785 | 671,316 |
| Events in quadrant D | 7,375,007 | 563,585 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 2 | 0 |
| B | 0 | 2 | 0 |
| C | 0 | 2 | 0 |
| D | 0 | 2 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15913 | 1 |
| B | 0 | 26183 | 1 |
| C | 0 | 15918 | 1 |
| D | 0 | 26975 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7307 | 82 | 1.122212% |
| B | 7308 | 1082 | 14.805692% |
| C | 7308 | 44 | 0.602080% |
| D | 7307 | 906 | 12.399069% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7442 | 7310 | 33 | 33 | 0.44% | 0.45% |  |
| B | 7443 | 7309 | 649 | 649 | 8.72% | 8.88% |  |
| C | 7443 | 7311 | 29 | 29 | 0.39% | 0.40% |  |
| D | 7442 | 7308 | 886 | 886 | 11.91% | 12.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 134943 | 663.85 | 817 | 795 | 202.1 |
| A | 13 | 248 | 95202 | 467.19 | 817 | 795 | 202.1 |
| A | 3 | 245 | 67550 | 330.35 | 817 | 795 | 202.1 |
| B | 2 | 249 | 1792626 | 11012.04 | 756 | 728 | 162.7 |
| B | 10 | 128 | 1691761 | 10392.18 | 756 | 728 | 162.7 |
| B | 0 | 153 | 115041 | 702.51 | 756 | 728 | 162.7 |
| C | 13 | 3 | 204374 | 943.48 | 787 | 780 | 215.8 |
| C | 12 | 252 | 91025 | 418.2 | 787 | 780 | 215.8 |
| C | 3 | 248 | 40665 | 184.83 | 787 | 780 | 215.8 |
| D | 2 | 31 | 2075789 | 9948.04 | 737 | 704 | 208.6 |
| D | 8 | 160 | 1472610 | 7056.37 | 737 | 704 | 208.6 |
| D | 7 | 222 | 258687 | 1236.78 | 737 | 704 | 208.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
