| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_042T02_9000006586_58212cztM0_level2.fits | modeM0/AS1A14_042T02_9000006586_58212cztM0_level2_quad_clean.evt |
| Size (bytes) | 573,958,080 | 108,000,000 |
| Size | 547.4 MB | 103.0 MB |
| Events in quadrant A | 3,728,569 | 733,438 |
| Events in quadrant B | 6,810,938 | 697,333 |
| Events in quadrant C | 3,306,050 | 694,925 |
| Events in quadrant D | 6,809,487 | 614,580 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 4 |
| B | 0 | 155 | 3 |
| C | 0 | 156 | 4 |
| D | 0 | 156 | 6 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17023 | 420 |
| B | 0 | 25977 | 634 |
| C | 0 | 16156 | 422 |
| D | 0 | 26819 | 1323 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7635 | 45 | 0.589391% |
| B | 7609 | 974 | 12.800631% |
| C | 7632 | 15 | 0.196541% |
| D | 7590 | 542 | 7.140975% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7689 | 7663 | 28 | 28 | 0.36% | 0.37% |  |
| B | 7670 | 7650 | 725 | 725 | 9.45% | 9.48% |  |
| C | 7713 | 7666 | 6 | 6 | 0.08% | 0.08% |  |
| D | 7700 | 7621 | 598 | 598 | 7.77% | 7.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 192440 | 923.97 | 834 | 813 | 207.4 |
| A | 7 | 64 | 110019 | 526.56 | 834 | 813 | 207.4 |
| A | 13 | 248 | 76558 | 365.22 | 834 | 813 | 207.4 |
| B | 2 | 249 | 2054844 | 12291.6 | 778 | 749 | 167.1 |
| B | 10 | 128 | 1079585 | 6455.7 | 778 | 749 | 167.1 |
| B | 0 | 153 | 100453 | 596.62 | 778 | 749 | 167.1 |
| C | 12 | 252 | 93430 | 416.3 | 805 | 796 | 222.5 |
| C | 14 | 254 | 24941 | 108.51 | 805 | 796 | 222.5 |
| C | 1 | 27 | 23663 | 102.77 | 805 | 796 | 222.5 |
| D | 12 | 110 | 1368020 | 6252.29 | 779 | 748 | 218.7 |
| D | 2 | 31 | 1025762 | 4687.21 | 779 | 748 | 218.7 |
| D | 8 | 240 | 366067 | 1670.54 | 779 | 748 | 218.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
