| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58267cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58267cztM0_level2_quad_clean.evt |
| Size (bytes) | 630,054,720 | 89,242,560 |
| Size | 600.9 MB | 85.1 MB |
| Events in quadrant A | 4,019,840 | 602,144 |
| Events in quadrant B | 5,431,503 | 588,328 |
| Events in quadrant C | 3,523,009 | 581,249 |
| Events in quadrant D | 9,847,245 | 478,669 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16466 | 1 |
| B | 0 | 20467 | 1 |
| C | 0 | 15329 | 1 |
| D | 0 | 33762 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6469 | 314 | 4.853919% |
| B | 6470 | 936 | 14.466770% |
| C | 6470 | 217 | 3.353941% |
| D | 6470 | 1306 | 20.185471% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7364 | 6469 | 135 | 135 | 1.83% | 2.09% |  |
| B | 7365 | 6470 | 496 | 496 | 6.73% | 7.67% |  |
| C | 7365 | 6471 | 70 | 70 | 0.95% | 1.08% |  |
| D | 7365 | 6470 | 1089 | 1089 | 14.79% | 16.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 463895 | 2691.25 | 707 | 689 | 172.1 |
| A | 13 | 248 | 372812 | 2162.06 | 707 | 689 | 172.1 |
| A | 12 | 114 | 149977 | 867.37 | 707 | 689 | 172.1 |
| B | 6 | 255 | 1200418 | 8441.82 | 666 | 642 | 142.1 |
| B | 2 | 249 | 754902 | 5307.1 | 666 | 642 | 142.1 |
| B | 4 | 206 | 197243 | 1383.32 | 666 | 642 | 142.1 |
| C | 12 | 249 | 455906 | 2422.48 | 686 | 678 | 187.9 |
| C | 6 | 223 | 193335 | 1025.22 | 686 | 678 | 187.9 |
| C | 15 | 204 | 69974 | 368.76 | 686 | 678 | 187.9 |
| D | 12 | 110 | 5583068 | 30171.3 | 651 | 622 | 185.0 |
| D | 8 | 160 | 870517 | 4701.5 | 651 | 622 | 185.0 |
| D | 3 | 47 | 219602 | 1183.52 | 651 | 622 | 185.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
