| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58269cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58269cztM0_level2_quad_clean.evt |
| Size (bytes) | 746,714,880 | 91,889,280 |
| Size | 712.1 MB | 87.6 MB |
| Events in quadrant A | 5,881,904 | 603,950 |
| Events in quadrant B | 5,708,471 | 649,015 |
| Events in quadrant C | 3,568,110 | 628,003 |
| Events in quadrant D | 11,932,602 | 406,769 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 22484 | 0 |
| B | 0 | 21781 | 0 |
| C | 0 | 16095 | 0 |
| D | 0 | 40349 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7094 | 859 | 12.108824% |
| B | 7095 | 891 | 12.558140% |
| C | 7095 | 219 | 3.086681% |
| D | 7095 | 2772 | 39.069767% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7094 | 7094 | 633 | 633 | 8.92% | 8.92% |  |
| B | 7095 | 7095 | 470 | 470 | 6.62% | 6.62% |  |
| C | 7095 | 7095 | 62 | 62 | 0.87% | 0.87% |  |
| D | 7095 | 7095 | 2179 | 2179 | 30.71% | 30.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 2358829 | 12508.13 | 762 | 741 | 188.5 |
| A | 13 | 248 | 260547 | 1378.1 | 762 | 741 | 188.5 |
| A | 8 | 249 | 95998 | 505.28 | 762 | 741 | 188.5 |
| B | 6 | 255 | 922395 | 5799.25 | 740 | 714 | 158.9 |
| B | 3 | 238 | 581116 | 3651.91 | 740 | 714 | 158.9 |
| B | 4 | 206 | 226281 | 1419.28 | 740 | 714 | 158.9 |
| C | 12 | 252 | 229350 | 1091.97 | 759 | 751 | 209.3 |
| C | 12 | 249 | 66440 | 313.78 | 759 | 751 | 209.3 |
| C | 15 | 204 | 52597 | 247.66 | 759 | 751 | 209.3 |
| D | 12 | 110 | 6893718 | 35657.04 | 677 | 647 | 193.3 |
| D | 2 | 120 | 1195394 | 6180.28 | 677 | 647 | 193.3 |
| D | 8 | 160 | 369583 | 1908.46 | 677 | 647 | 193.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
