| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58323cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58323cztM0_level2_quad_clean.evt |
| Size (bytes) | 486,385,920 | 93,323,520 |
| Size | 463.9 MB | 89.0 MB |
| Events in quadrant A | 3,364,327 | 637,427 |
| Events in quadrant B | 7,741,673 | 550,577 |
| Events in quadrant C | 2,999,635 | 619,178 |
| Events in quadrant D | 3,403,357 | 573,948 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14340 | 1 |
| B | 0 | 27460 | 1 |
| C | 0 | 13408 | 1 |
| D | 0 | 14559 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6372 | 73 | 1.145637% |
| B | 6372 | 1576 | 24.733208% |
| C | 6372 | 19 | 0.298180% |
| D | 6373 | 74 | 1.161149% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7597 | 6373 | 50 | 50 | 0.66% | 0.78% |  |
| B | 7597 | 6373 | 1188 | 1188 | 15.64% | 18.64% |  |
| C | 7597 | 6373 | 21 | 21 | 0.28% | 0.33% |  |
| D | 7598 | 6374 | 76 | 76 | 1.00% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 159356 | 896.08 | 713 | 695 | 177.1 |
| A | 13 | 248 | 101893 | 571.54 | 713 | 695 | 177.1 |
| A | 10 | 251 | 83110 | 465.46 | 713 | 695 | 177.1 |
| B | 10 | 128 | 3705498 | 27171.01 | 638 | 616 | 136.4 |
| B | 2 | 249 | 755152 | 5533.65 | 638 | 616 | 136.4 |
| B | 5 | 185 | 397591 | 2911.35 | 638 | 616 | 136.4 |
| C | 6 | 223 | 115319 | 599.06 | 692 | 685 | 191.4 |
| C | 6 | 13 | 52960 | 273.18 | 692 | 685 | 191.4 |
| C | 11 | 244 | 36396 | 186.62 | 692 | 685 | 191.4 |
| D | 11 | 176 | 374679 | 1920.01 | 683 | 652 | 194.8 |
| D | 11 | 129 | 228515 | 1169.7 | 683 | 652 | 194.8 |
| D | 3 | 12 | 49990 | 253.27 | 683 | 652 | 194.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
