| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58338cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58338cztM0_level2_quad_clean.evt |
| Size (bytes) | 372,856,320 | 99,115,200 |
| Size | 355.6 MB | 94.5 MB |
| Events in quadrant A | 3,082,466 | 648,445 |
| Events in quadrant B | 3,555,587 | 696,168 |
| Events in quadrant C | 3,434,737 | 621,788 |
| Events in quadrant D | 3,228,458 | 586,209 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13612 | 2 |
| B | 0 | 14781 | 2 |
| C | 0 | 14752 | 3 |
| D | 0 | 14144 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6430 | 93 | 1.446345% |
| B | 6430 | 172 | 2.674961% |
| C | 6429 | 143 | 2.224296% |
| D | 6429 | 74 | 1.151034% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 6431 | 8 | 8 | 0.11% | 0.12% |  |
| B | 7590 | 6431 | 30 | 30 | 0.40% | 0.47% |  |
| C | 7589 | 6430 | 96 | 96 | 1.26% | 1.49% |  |
| D | 7589 | 6430 | 34 | 34 | 0.45% | 0.53% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 58414 | 314.47 | 739 | 718 | 183.5 |
| A | 2 | 143 | 28128 | 149.4 | 739 | 718 | 183.5 |
| A | 0 | 117 | 19466 | 102.19 | 739 | 718 | 183.5 |
| B | 8 | 234 | 153697 | 985.66 | 728 | 702 | 155.2 |
| B | 4 | 171 | 118342 | 757.88 | 728 | 702 | 155.2 |
| B | 5 | 185 | 70588 | 450.23 | 728 | 702 | 155.2 |
| C | 15 | 198 | 267911 | 1369.15 | 711 | 705 | 195.2 |
| C | 6 | 223 | 95199 | 484.18 | 711 | 705 | 195.2 |
| C | 12 | 252 | 76516 | 388.45 | 711 | 705 | 195.2 |
| D | 2 | 31 | 107031 | 531.28 | 707 | 676 | 200.2 |
| D | 11 | 176 | 90338 | 447.89 | 707 | 676 | 200.2 |
| D | 12 | 110 | 80737 | 399.93 | 707 | 676 | 200.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
