| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58350cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58350cztM0_level2_quad_clean.evt |
| Size (bytes) | 381,784,320 | 92,194,560 |
| Size | 364.1 MB | 87.9 MB |
| Events in quadrant A | 3,087,038 | 597,187 |
| Events in quadrant B | 4,277,032 | 625,905 |
| Events in quadrant C | 3,246,341 | 575,706 |
| Events in quadrant D | 3,020,113 | 543,230 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13875 | 2 |
| B | 0 | 17151 | 3 |
| C | 0 | 14516 | 2 |
| D | 0 | 13810 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6448 | 56 | 0.868486% |
| B | 6447 | 276 | 4.281061% |
| C | 6447 | 123 | 1.907864% |
| D | 6447 | 53 | 0.822088% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7671 | 6632 | 24 | 24 | 0.31% | 0.36% |  |
| B | 7670 | 6631 | 182 | 182 | 2.37% | 2.74% |  |
| C | 7670 | 6631 | 86 | 86 | 1.12% | 1.30% |  |
| D | 7670 | 6631 | 17 | 17 | 0.22% | 0.26% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 221221 | 1263.75 | 700 | 682 | 174.5 |
| A | 13 | 248 | 37454 | 210.71 | 700 | 682 | 174.5 |
| A | 12 | 114 | 22575 | 125.45 | 700 | 682 | 174.5 |
| B | 10 | 128 | 705777 | 4774.28 | 689 | 662 | 147.7 |
| B | 5 | 185 | 542872 | 3671.26 | 689 | 662 | 147.7 |
| B | 0 | 156 | 52049 | 347.93 | 689 | 662 | 147.7 |
| C | 9 | 38 | 296417 | 1562.8 | 680 | 674 | 189.2 |
| C | 4 | 5 | 153512 | 807.64 | 680 | 674 | 189.2 |
| C | 12 | 252 | 40319 | 209.5 | 680 | 674 | 189.2 |
| D | 11 | 129 | 181618 | 937.78 | 680 | 649 | 193.0 |
| D | 3 | 12 | 80226 | 412.37 | 680 | 649 | 193.0 |
| D | 5 | 173 | 47622 | 243.41 | 680 | 649 | 193.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
