| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58356cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58356cztM0_level2_quad_clean.evt |
| Size (bytes) | 765,227,520 | 82,143,360 |
| Size | 729.8 MB | 78.3 MB |
| Events in quadrant A | 4,296,181 | 626,461 |
| Events in quadrant B | 9,236,463 | 552,248 |
| Events in quadrant C | 10,376,174 | 226,009 |
| Events in quadrant D | 3,867,654 | 589,789 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17742 | 3 |
| B | 0 | 32400 | 3 |
| C | 0 | 35789 | 3 |
| D | 0 | 16305 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7068 | 500 | 7.074137% |
| B | 7069 | 1969 | 27.854010% |
| C | 7069 | 4702 | 66.515773% |
| D | 7069 | 246 | 3.479983% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7138 | 7071 | 206 | 206 | 2.89% | 2.91% |  |
| B | 7139 | 7072 | 1297 | 1297 | 18.17% | 18.34% |  |
| C | 7138 | 7069 | 1964 | 1964 | 27.51% | 27.78% |  |
| D | 7139 | 7072 | 52 | 52 | 0.73% | 0.74% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 246 | 463984 | 2409.09 | 778 | 756 | 192.3 |
| A | 12 | 80 | 316335 | 1641.22 | 778 | 756 | 192.3 |
| A | 8 | 249 | 142222 | 735.72 | 778 | 756 | 192.3 |
| B | 10 | 128 | 4263866 | 27728.77 | 719 | 693 | 153.7 |
| B | 3 | 238 | 931085 | 6051.51 | 719 | 693 | 153.7 |
| B | 6 | 255 | 444018 | 2883.5 | 719 | 693 | 153.7 |
| C | 15 | 148 | 8632971 | 82725.59 | 377 | 372 | 104.4 |
| C | 12 | 252 | 92576 | 883.58 | 377 | 372 | 104.4 |
| C | 6 | 13 | 53526 | 509.37 | 377 | 372 | 104.4 |
| D | 8 | 160 | 168441 | 779.6 | 770 | 737 | 215.1 |
| D | 3 | 12 | 145637 | 673.59 | 770 | 737 | 215.1 |
| D | 11 | 129 | 112198 | 518.14 | 770 | 737 | 215.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
