| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58357cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58357cztM0_level2_quad_clean.evt |
| Size (bytes) | 843,258,240 | 77,921,280 |
| Size | 804.2 MB | 74.3 MB |
| Events in quadrant A | 3,629,247 | 655,866 |
| Events in quadrant B | 7,951,652 | 580,452 |
| Events in quadrant C | 15,164,835 | 36,656 |
| Events in quadrant D | 3,921,131 | 595,562 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15786 | 0 |
| B | 0 | 28483 | 0 |
| C | 0 | 49794 | 0 |
| D | 0 | 16423 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7044 | 126 | 1.788756% |
| B | 7044 | 1562 | 22.174901% |
| C | 7044 | 6731 | 95.556502% |
| D | 7044 | 80 | 1.135718% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7044 | 7044 | 105 | 105 | 1.49% | 1.49% |  |
| B | 7044 | 7044 | 1138 | 1138 | 16.16% | 16.16% |  |
| C | 7043 | 7043 | 4783 | 4783 | 67.91% | 67.91% |  |
| D | 7044 | 7044 | 84 | 84 | 1.19% | 1.19% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 342414 | 1823.74 | 759 | 737 | 187.3 |
| A | 13 | 248 | 60095 | 316.83 | 759 | 737 | 187.3 |
| A | 3 | 245 | 40300 | 211.17 | 759 | 737 | 187.3 |
| B | 6 | 255 | 2990939 | 20376.69 | 687 | 664 | 146.7 |
| B | 10 | 128 | 1172346 | 7984.22 | 687 | 664 | 146.7 |
| B | 3 | 238 | 307226 | 2089.01 | 687 | 664 | 146.7 |
| C | 15 | 148 | 14118712 | 218760.43 | 229 | 228 | 64.5 |
| C | 12 | 252 | 79975 | 1235.65 | 229 | 228 | 64.5 |
| C | 4 | 5 | 16089 | 245.76 | 229 | 228 | 64.5 |
| D | 2 | 249 | 255117 | 1226.95 | 739 | 707 | 207.4 |
| D | 3 | 12 | 239618 | 1152.21 | 739 | 707 | 207.4 |
| D | 2 | 31 | 148990 | 715.13 | 739 | 707 | 207.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
