| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T03_9000006588_58367cztM0_level2.fits | modeM0/AS1A14_044T03_9000006588_58367cztM0_level2_quad_clean.evt |
| Size (bytes) | 387,950,400 | 94,095,360 |
| Size | 370.0 MB | 89.7 MB |
| Events in quadrant A | 2,991,603 | 622,942 |
| Events in quadrant B | 5,023,333 | 623,172 |
| Events in quadrant C | 2,961,305 | 604,050 |
| Events in quadrant D | 2,900,226 | 565,646 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13305 | 1 |
| B | 0 | 19033 | 1 |
| C | 0 | 13265 | 1 |
| D | 0 | 13111 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6219 | 74 | 1.189902% |
| B | 6219 | 600 | 9.647853% |
| C | 6219 | 31 | 0.498472% |
| D | 6220 | 28 | 0.450161% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7434 | 6219 | 19 | 19 | 0.26% | 0.31% |  |
| B | 7434 | 6220 | 377 | 377 | 5.07% | 6.06% |  |
| C | 7434 | 6220 | 22 | 22 | 0.30% | 0.35% |  |
| D | 7435 | 6221 | 13 | 13 | 0.17% | 0.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 248 | 101058 | 590.25 | 694 | 676 | 170.1 |
| A | 4 | 249 | 43579 | 252.27 | 694 | 676 | 170.1 |
| A | 8 | 246 | 41085 | 237.61 | 694 | 676 | 170.1 |
| B | 5 | 172 | 1638501 | 11595.03 | 661 | 636 | 141.3 |
| B | 10 | 128 | 373985 | 2643.07 | 661 | 636 | 141.3 |
| B | 5 | 185 | 98395 | 692.07 | 661 | 636 | 141.3 |
| C | 4 | 5 | 106102 | 568.22 | 674 | 668 | 185.6 |
| C | 14 | 245 | 44153 | 234.36 | 674 | 668 | 185.6 |
| C | 11 | 244 | 27626 | 145.29 | 674 | 668 | 185.6 |
| D | 11 | 129 | 95607 | 501.41 | 669 | 638 | 189.4 |
| D | 8 | 160 | 58799 | 307.07 | 669 | 638 | 189.4 |
| D | 3 | 12 | 43956 | 228.71 | 669 | 638 | 189.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
