| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_045T01_9000006590_58401cztM0_level2.fits | modeM0/AS1A14_045T01_9000006590_58401cztM0_level2_quad_clean.evt |
| Size (bytes) | 917,406,720 | 108,207,360 |
| Size | 874.9 MB | 103.2 MB |
| Events in quadrant A | 8,315,203 | 654,708 |
| Events in quadrant B | 8,018,736 | 773,799 |
| Events in quadrant C | 9,322,899 | 597,932 |
| Events in quadrant D | 7,667,742 | 678,329 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 0 |
| B | 0 | 164 | 0 |
| C | 0 | 164 | 0 |
| D | 0 | 164 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 30367 | 0 |
| B | 0 | 29605 | 0 |
| C | 0 | 33476 | 0 |
| D | 0 | 28590 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8220 | 1480 | 18.004866% |
| B | 8221 | 1054 | 12.820825% |
| C | 8221 | 1897 | 23.075052% |
| D | 8221 | 490 | 5.960345% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8220 | 8220 | 1101 | 1101 | 13.39% | 13.39% |  |
| B | 8221 | 8221 | 652 | 652 | 7.93% | 7.93% |  |
| C | 8221 | 8221 | 1446 | 1446 | 17.59% | 17.59% |  |
| D | 8221 | 8221 | 419 | 419 | 5.10% | 5.10% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 4005452 | 18421.86 | 883 | 862 | 217.4 |
| A | 12 | 80 | 397740 | 1825.71 | 883 | 862 | 217.4 |
| A | 7 | 64 | 145244 | 664.18 | 883 | 862 | 217.4 |
| B | 5 | 172 | 2936125 | 15238.72 | 895 | 861 | 192.6 |
| B | 4 | 158 | 600300 | 3112.05 | 895 | 861 | 192.6 |
| B | 6 | 255 | 282482 | 1462.06 | 895 | 861 | 192.6 |
| C | 9 | 38 | 3079573 | 13889.86 | 810 | 804 | 221.7 |
| C | 6 | 223 | 1654763 | 7461.83 | 810 | 804 | 221.7 |
| C | 15 | 147 | 623216 | 2808.01 | 810 | 804 | 221.7 |
| D | 5 | 113 | 2012795 | 7910.92 | 889 | 843 | 254.3 |
| D | 8 | 240 | 765395 | 3006.19 | 889 | 843 | 254.3 |
| D | 2 | 249 | 699465 | 2746.96 | 889 | 843 | 254.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
