| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_045T01_9000006590_58412cztM0_level2.fits | modeM0/AS1A14_045T01_9000006590_58412cztM0_level2_quad_clean.evt |
| Size (bytes) | 3,940,617,600 | 453,625,920 |
| Size | 3.7 GB | 432.6 MB |
| Events in quadrant A | 35,180,013 | 3,275,907 |
| Events in quadrant B | 64,131,831 | 1,562,902 |
| Events in quadrant C | 19,872,490 | 3,357,349 |
| Events in quadrant D | 23,918,816 | 3,073,868 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 728 | 0 |
| B | 0 | 728 | 0 |
| C | 0 | 728 | 0 |
| D | 0 | 728 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 129348 | 82 |
| B | 0 | 215265 | 201 |
| C | 0 | 83844 | 26 |
| D | 0 | 96146 | 35 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 76 | 0 |
| B | 0 | 76 | 0 |
| C | 0 | 76 | 0 |
| D | 0 | 76 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 35865 | 3581 | 9.984665% |
| B | 35851 | 22173 | 61.847647% |
| C | 35873 | 548 | 1.527611% |
| D | 35870 | 1263 | 3.521048% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 43350 | 35887 | 2797 | 2797 | 6.45% | 7.79% |  |
| B | 43351 | 35874 | 14968 | 14968 | 34.53% | 41.72% |  |
| C | 43350 | 35887 | 308 | 308 | 0.71% | 0.86% |  |
| D | 43350 | 35887 | 947 | 947 | 2.18% | 2.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 6568516 | 6840.15 | 3910 | 3818 | 959.7 |
| A | 3 | 14 | 6292428 | 6552.48 | 3910 | 3818 | 959.7 |
| A | 4 | 249 | 3350087 | 3486.68 | 3910 | 3818 | 959.7 |
| B | 6 | 255 | 48706707 | 86073.97 | 2663 | 2558 | 565.8 |
| B | 5 | 172 | 2502181 | 4417.54 | 2663 | 2558 | 565.8 |
| B | 4 | 158 | 1038732 | 1831.21 | 2663 | 2558 | 565.8 |
| C | 9 | 38 | 1380636 | 1303.16 | 3873 | 3839 | 1056.5 |
| C | 5 | 10 | 843073 | 794.35 | 3873 | 3839 | 1056.5 |
| C | 13 | 3 | 739121 | 695.96 | 3873 | 3839 | 1056.5 |
| D | 12 | 110 | 3681458 | 3393.86 | 3816 | 3650 | 1083.7 |
| D | 8 | 240 | 2875081 | 2649.74 | 3816 | 3650 | 1083.7 |
| D | 2 | 249 | 627381 | 575.57 | 3816 | 3650 | 1083.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
