| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_045T01_9000006590_58441cztM0_level2.fits | modeM0/AS1A14_045T01_9000006590_58441cztM0_level2_quad_clean.evt |
| Size (bytes) | 418,691,520 | 98,375,040 |
| Size | 399.3 MB | 93.8 MB |
| Events in quadrant A | 3,453,258 | 646,096 |
| Events in quadrant B | 3,432,296 | 698,181 |
| Events in quadrant C | 4,396,374 | 599,567 |
| Events in quadrant D | 3,709,378 | 580,129 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14747 | 2 |
| B | 0 | 14571 | 2 |
| C | 0 | 17618 | 3 |
| D | 0 | 15672 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6518 | 156 | 2.393372% |
| B | 6518 | 212 | 3.252531% |
| C | 6517 | 440 | 6.751573% |
| D | 6517 | 131 | 2.010127% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7638 | 6519 | 65 | 65 | 0.85% | 1.00% |  |
| B | 7638 | 6519 | 73 | 73 | 0.96% | 1.12% |  |
| C | 7637 | 6518 | 312 | 312 | 4.09% | 4.79% |  |
| D | 7637 | 6518 | 70 | 70 | 0.92% | 1.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 62 | 354650 | 1908.08 | 753 | 734 | 185.5 |
| A | 12 | 114 | 53751 | 285.83 | 753 | 734 | 185.5 |
| A | 10 | 251 | 41637 | 220.52 | 753 | 734 | 185.5 |
| B | 4 | 201 | 170158 | 1053.58 | 745 | 719 | 160.8 |
| B | 10 | 246 | 71915 | 442.7 | 745 | 719 | 160.8 |
| B | 8 | 128 | 50273 | 308.13 | 745 | 719 | 160.8 |
| C | 1 | 12 | 1064907 | 5439.98 | 713 | 709 | 195.6 |
| C | 12 | 249 | 160741 | 818.05 | 713 | 709 | 195.6 |
| C | 14 | 245 | 137633 | 699.93 | 713 | 709 | 195.6 |
| D | 8 | 240 | 369984 | 1787.41 | 720 | 688 | 206.6 |
| D | 2 | 249 | 112603 | 541.67 | 720 | 688 | 206.6 |
| D | 12 | 248 | 97680 | 469.45 | 720 | 688 | 206.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
