| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_045T01_9000006590_58450cztM0_level2.fits | modeM0/AS1A14_045T01_9000006590_58450cztM0_level2_quad_clean.evt |
| Size (bytes) | 431,726,400 | 96,744,960 |
| Size | 411.7 MB | 92.3 MB |
| Events in quadrant A | 2,981,478 | 642,667 |
| Events in quadrant B | 3,564,995 | 682,605 |
| Events in quadrant C | 4,143,838 | 579,297 |
| Events in quadrant D | 4,768,865 | 556,812 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13871 | 2 |
| B | 0 | 15265 | 2 |
| C | 0 | 17150 | 3 |
| D | 0 | 18797 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6705 | 47 | 0.700969% |
| B | 6705 | 120 | 1.789709% |
| C | 6704 | 476 | 7.100239% |
| D | 6705 | 400 | 5.965697% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7650 | 6705 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7650 | 6705 | 44 | 44 | 0.58% | 0.66% |  |
| C | 7649 | 6704 | 362 | 362 | 4.73% | 5.40% |  |
| D | 7650 | 6705 | 333 | 333 | 4.35% | 4.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 248 | 36192 | 194.73 | 734 | 715 | 182.2 |
| A | 12 | 80 | 33683 | 180.96 | 734 | 715 | 182.2 |
| A | 3 | 14 | 22630 | 120.29 | 734 | 715 | 182.2 |
| B | 5 | 172 | 206294 | 1323.24 | 725 | 699 | 155.4 |
| B | 0 | 156 | 69774 | 444.58 | 725 | 699 | 155.4 |
| B | 10 | 247 | 67422 | 429.44 | 725 | 699 | 155.4 |
| C | 1 | 12 | 1129766 | 5994.25 | 688 | 684 | 188.4 |
| C | 13 | 3 | 152570 | 806.36 | 688 | 684 | 188.4 |
| C | 4 | 5 | 43449 | 227.04 | 688 | 684 | 188.4 |
| D | 8 | 240 | 1196133 | 6008.8 | 695 | 663 | 199.0 |
| D | 2 | 249 | 477251 | 2395.48 | 695 | 663 | 199.0 |
| D | 2 | 31 | 120334 | 601.5 | 695 | 663 | 199.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
