| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58464cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58464cztM0_level2_quad_clean.evt |
| Size (bytes) | 627,865,920 | 86,267,520 |
| Size | 598.8 MB | 82.3 MB |
| Events in quadrant A | 3,232,930 | 635,660 |
| Events in quadrant B | 11,263,671 | 352,900 |
| Events in quadrant C | 4,376,717 | 591,220 |
| Events in quadrant D | 3,849,316 | 566,034 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14454 | 2 |
| B | 0 | 38050 | 2 |
| C | 0 | 17817 | 2 |
| D | 0 | 16162 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6676 | 92 | 1.378071% |
| B | 6676 | 3444 | 51.587777% |
| C | 6677 | 342 | 5.122061% |
| D | 6677 | 174 | 2.605961% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7566 | 6677 | 47 | 47 | 0.62% | 0.70% |  |
| B | 7566 | 6676 | 3052 | 3052 | 40.34% | 45.72% |  |
| C | 7567 | 6679 | 331 | 331 | 4.37% | 4.96% |  |
| D | 7567 | 6678 | 147 | 147 | 1.94% | 2.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 265252 | 1466.1 | 726 | 709 | 180.4 |
| A | 3 | 14 | 29282 | 158.35 | 726 | 709 | 180.4 |
| A | 12 | 114 | 26289 | 141.76 | 726 | 709 | 180.4 |
| B | 2 | 249 | 8104636 | 78757.44 | 477 | 459 | 102.9 |
| B | 5 | 172 | 733023 | 7119.15 | 477 | 459 | 102.9 |
| B | 8 | 128 | 295258 | 2864.89 | 477 | 459 | 102.9 |
| C | 5 | 10 | 624471 | 3268.39 | 695 | 690 | 190.9 |
| C | 4 | 5 | 359422 | 1879.63 | 695 | 690 | 190.9 |
| C | 6 | 223 | 298523 | 1560.54 | 695 | 690 | 190.9 |
| D | 8 | 240 | 667101 | 3356.32 | 698 | 665 | 198.6 |
| D | 1 | 3 | 146751 | 735.72 | 698 | 665 | 198.6 |
| D | 2 | 31 | 62178 | 309.79 | 698 | 665 | 198.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
