| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58466cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58466cztM0_level2_quad_clean.evt |
| Size (bytes) | 622,745,280 | 86,639,040 |
| Size | 593.9 MB | 82.6 MB |
| Events in quadrant A | 2,978,579 | 634,541 |
| Events in quadrant B | 9,764,143 | 421,366 |
| Events in quadrant C | 4,893,036 | 575,393 |
| Events in quadrant D | 4,909,269 | 536,570 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13701 | 2 |
| B | 0 | 33479 | 3 |
| C | 0 | 19177 | 2 |
| D | 0 | 19174 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6528 | 49 | 0.750613% |
| B | 6527 | 2697 | 41.320668% |
| C | 6527 | 517 | 7.920944% |
| D | 6527 | 475 | 7.277463% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7588 | 6529 | 22 | 22 | 0.29% | 0.34% |  |
| B | 7586 | 6526 | 2459 | 2459 | 32.41% | 37.68% |  |
| C | 7586 | 6526 | 461 | 461 | 6.08% | 7.06% |  |
| D | 7586 | 6527 | 513 | 513 | 6.76% | 7.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 92400 | 517.62 | 711 | 693 | 177.2 |
| A | 2 | 143 | 33531 | 185.35 | 711 | 693 | 177.2 |
| A | 4 | 238 | 32356 | 178.71 | 711 | 693 | 177.2 |
| B | 2 | 249 | 6874601 | 61833.65 | 517 | 497 | 111.2 |
| B | 5 | 172 | 526464 | 4731.16 | 517 | 497 | 111.2 |
| B | 5 | 185 | 77415 | 691.89 | 517 | 497 | 111.2 |
| C | 5 | 10 | 1407429 | 7596.49 | 672 | 667 | 185.2 |
| C | 4 | 5 | 387887 | 2090.98 | 672 | 667 | 185.2 |
| C | 6 | 223 | 256127 | 1379.48 | 672 | 667 | 185.2 |
| D | 1 | 3 | 772467 | 4031.72 | 670 | 639 | 191.4 |
| D | 8 | 240 | 606799 | 3166.34 | 670 | 639 | 191.4 |
| D | 2 | 153 | 347072 | 1809.63 | 670 | 639 | 191.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
