| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58470cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58470cztM0_level2_quad_clean.evt |
| Size (bytes) | 470,381,760 | 99,956,160 |
| Size | 448.6 MB | 95.3 MB |
| Events in quadrant A | 3,457,513 | 673,776 |
| Events in quadrant B | 5,558,643 | 671,105 |
| Events in quadrant C | 4,053,231 | 623,977 |
| Events in quadrant D | 3,824,202 | 592,568 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14790 | 2 |
| B | 0 | 20880 | 4 |
| C | 0 | 16773 | 2 |
| D | 0 | 16051 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 23 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6667 | 115 | 1.724914% |
| B | 6666 | 747 | 11.206121% |
| C | 6666 | 315 | 4.725473% |
| D | 6667 | 188 | 2.819859% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9077 | 6669 | 31 | 31 | 0.34% | 0.46% |  |
| B | 9076 | 6668 | 544 | 544 | 5.99% | 8.16% |  |
| C | 9076 | 6668 | 258 | 258 | 2.84% | 3.87% |  |
| D | 9077 | 6669 | 156 | 156 | 1.72% | 2.34% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 266988 | 1408.85 | 766 | 747 | 189.0 |
| A | 3 | 14 | 86927 | 456.03 | 766 | 747 | 189.0 |
| A | 3 | 245 | 35390 | 183.32 | 766 | 747 | 189.0 |
| B | 2 | 249 | 1301289 | 8331.1 | 727 | 700 | 156.1 |
| B | 5 | 172 | 1077683 | 6898.76 | 727 | 700 | 156.1 |
| B | 0 | 157 | 97990 | 623.2 | 727 | 700 | 156.1 |
| C | 1 | 12 | 504777 | 2533.98 | 727 | 722 | 198.9 |
| C | 6 | 223 | 355523 | 1783.65 | 727 | 722 | 198.9 |
| C | 12 | 249 | 67823 | 337.33 | 727 | 722 | 198.9 |
| D | 8 | 240 | 780595 | 3764.33 | 727 | 696 | 207.2 |
| D | 5 | 173 | 43732 | 207.72 | 727 | 696 | 207.2 |
| D | 2 | 120 | 42480 | 201.68 | 727 | 696 | 207.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
