| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58472cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58472cztM0_level2_quad_clean.evt |
| Size (bytes) | 449,680,320 | 102,697,920 |
| Size | 428.8 MB | 97.9 MB |
| Events in quadrant A | 3,561,034 | 664,137 |
| Events in quadrant B | 4,374,951 | 716,712 |
| Events in quadrant C | 4,353,931 | 630,920 |
| Events in quadrant D | 3,803,570 | 603,512 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15642 | 1 |
| B | 0 | 17733 | 1 |
| C | 0 | 18009 | 1 |
| D | 0 | 16516 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7100 | 200 | 2.816901% |
| B | 7100 | 260 | 3.661972% |
| C | 7100 | 327 | 4.605634% |
| D | 7100 | 173 | 2.436620% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 7101 | 44 | 44 | 0.58% | 0.62% |  |
| B | 7590 | 7101 | 32 | 32 | 0.42% | 0.45% |  |
| C | 7590 | 7101 | 208 | 208 | 2.74% | 2.93% |  |
| D | 7590 | 7101 | 99 | 99 | 1.30% | 1.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 264569 | 1325.13 | 802 | 781 | 199.1 |
| A | 12 | 114 | 79897 | 397.44 | 802 | 781 | 199.1 |
| A | 12 | 80 | 22390 | 108.55 | 802 | 781 | 199.1 |
| B | 5 | 172 | 904285 | 5251.29 | 790 | 761 | 172.1 |
| B | 6 | 255 | 89307 | 514.63 | 790 | 761 | 172.1 |
| B | 2 | 249 | 88460 | 509.71 | 790 | 761 | 172.1 |
| C | 5 | 10 | 518464 | 2450.68 | 768 | 760 | 211.2 |
| C | 4 | 5 | 375811 | 1775.4 | 768 | 760 | 211.2 |
| C | 14 | 245 | 140070 | 659.46 | 768 | 760 | 211.2 |
| D | 8 | 240 | 441823 | 2016.84 | 773 | 739 | 218.7 |
| D | 2 | 120 | 162321 | 738.83 | 773 | 739 | 218.7 |
| D | 3 | 12 | 71475 | 323.44 | 773 | 739 | 218.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
