| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58473cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58473cztM0_level2_quad_clean.evt |
| Size (bytes) | 528,275,520 | 122,160,960 |
| Size | 503.8 MB | 116.5 MB |
| Events in quadrant A | 4,300,962 | 794,305 |
| Events in quadrant B | 4,775,558 | 851,638 |
| Events in quadrant C | 5,051,008 | 757,752 |
| Events in quadrant D | 4,771,403 | 708,622 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18785 | 1 |
| B | 0 | 19794 | 1 |
| C | 0 | 20991 | 1 |
| D | 0 | 20251 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 172 | 0 |
| B | 0 | 172 | 0 |
| C | 0 | 172 | 0 |
| D | 0 | 172 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8443 | 214 | 2.534644% |
| B | 8443 | 376 | 4.453393% |
| C | 8443 | 328 | 3.884875% |
| D | 8443 | 285 | 3.375577% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8933 | 8444 | 21 | 21 | 0.24% | 0.25% |  |
| B | 8933 | 8444 | 26 | 26 | 0.29% | 0.31% |  |
| C | 8933 | 8444 | 176 | 176 | 1.97% | 2.08% |  |
| D | 8933 | 8444 | 171 | 171 | 1.91% | 2.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 233498 | 949.9 | 984 | 957 | 244.8 |
| A | 12 | 114 | 82228 | 331.98 | 984 | 957 | 244.8 |
| A | 12 | 80 | 62915 | 253.09 | 984 | 957 | 244.8 |
| B | 5 | 172 | 480542 | 2297.29 | 968 | 930 | 208.8 |
| B | 2 | 249 | 161226 | 767.8 | 968 | 930 | 208.8 |
| B | 10 | 247 | 99519 | 472.23 | 968 | 930 | 208.8 |
| C | 5 | 10 | 537949 | 2073.11 | 945 | 938 | 259.0 |
| C | 6 | 223 | 233034 | 896.0 | 945 | 938 | 259.0 |
| C | 4 | 5 | 224726 | 863.93 | 945 | 938 | 259.0 |
| D | 10 | 86 | 428978 | 1615.5 | 942 | 901 | 265.0 |
| D | 8 | 240 | 389573 | 1466.79 | 942 | 901 | 265.0 |
| D | 5 | 173 | 64142 | 238.66 | 942 | 901 | 265.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
