| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58477cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58477cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,561,714,560 | 261,276,480 |
| Size | 1.5 GB | 249.2 MB |
| Events in quadrant A | 11,479,675 | 1,752,886 |
| Events in quadrant B | 15,635,139 | 1,738,597 |
| Events in quadrant C | 16,767,875 | 1,503,442 |
| Events in quadrant D | 12,437,449 | 1,587,778 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 47228 | 2 |
| B | 0 | 59595 | 2 |
| C | 0 | 63356 | 2 |
| D | 0 | 50447 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 390 | 0 |
| B | 0 | 390 | 0 |
| C | 0 | 390 | 0 |
| D | 0 | 390 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19264 | 839 | 4.355274% |
| B | 19264 | 2407 | 12.494809% |
| C | 19264 | 2574 | 13.361711% |
| D | 19265 | 836 | 4.339476% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20039 | 19266 | 419 | 419 | 2.09% | 2.17% |  |
| B | 20039 | 19266 | 1515 | 1515 | 7.56% | 7.86% |  |
| C | 20039 | 19266 | 2174 | 2174 | 10.85% | 11.28% |  |
| D | 20040 | 19267 | 564 | 564 | 2.81% | 2.93% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 1372022 | 2571.12 | 2146 | 2093 | 532.8 |
| A | 10 | 251 | 522096 | 975.96 | 2146 | 2093 | 532.8 |
| A | 7 | 64 | 384090 | 716.94 | 2146 | 2093 | 532.8 |
| B | 5 | 172 | 3798306 | 8772.89 | 2031 | 1955 | 432.7 |
| B | 2 | 249 | 2955537 | 6825.36 | 2031 | 1955 | 432.7 |
| B | 10 | 247 | 220156 | 504.24 | 2031 | 1955 | 432.7 |
| C | 15 | 147 | 5271865 | 9688.43 | 1999 | 1985 | 543.9 |
| C | 5 | 10 | 1637392 | 3006.62 | 1999 | 1985 | 543.9 |
| C | 15 | 1 | 579759 | 1062.21 | 1999 | 1985 | 543.9 |
| D | 8 | 240 | 2481043 | 4218.08 | 2073 | 1977 | 587.7 |
| D | 2 | 153 | 977891 | 1660.5 | 2073 | 1977 | 587.7 |
| D | 3 | 12 | 247109 | 417.09 | 2073 | 1977 | 587.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
