| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58481cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58481cztM0_level2_quad_clean.evt |
| Size (bytes) | 628,963,200 | 87,056,640 |
| Size | 599.8 MB | 83.0 MB |
| Events in quadrant A | 5,453,528 | 605,504 |
| Events in quadrant B | 10,328,165 | 383,552 |
| Events in quadrant C | 3,427,974 | 613,480 |
| Events in quadrant D | 3,565,644 | 577,606 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20613 | 2 |
| B | 0 | 35211 | 7 |
| C | 0 | 14863 | 2 |
| D | 0 | 15290 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6532 | 486 | 7.440294% |
| B | 6531 | 3006 | 46.026642% |
| C | 6531 | 93 | 1.423978% |
| D | 6531 | 65 | 0.995253% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7617 | 6533 | 426 | 426 | 5.59% | 6.52% |  |
| B | 7615 | 6531 | 2455 | 2455 | 32.24% | 37.59% |  |
| C | 7616 | 6532 | 68 | 68 | 0.89% | 1.04% |  |
| D | 7616 | 6532 | 41 | 41 | 0.54% | 0.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 1348165 | 7741.72 | 698 | 680 | 174.1 |
| A | 12 | 80 | 330211 | 1893.26 | 698 | 680 | 174.1 |
| A | 11 | 3 | 239484 | 1372.0 | 698 | 680 | 174.1 |
| B | 2 | 249 | 6285169 | 56534.12 | 511 | 492 | 111.2 |
| B | 5 | 172 | 1646349 | 14805.39 | 511 | 492 | 111.2 |
| B | 0 | 186 | 201363 | 1806.95 | 511 | 492 | 111.2 |
| C | 5 | 10 | 349718 | 1808.19 | 698 | 693 | 193.0 |
| C | 14 | 245 | 60201 | 308.29 | 698 | 693 | 193.0 |
| C | 12 | 249 | 59057 | 302.37 | 698 | 693 | 193.0 |
| D | 8 | 240 | 243670 | 1239.7 | 692 | 663 | 196.0 |
| D | 0 | 97 | 219986 | 1118.88 | 692 | 663 | 196.0 |
| D | 3 | 12 | 203744 | 1036.02 | 692 | 663 | 196.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
