| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58483cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58483cztM0_level2_quad_clean.evt |
| Size (bytes) | 506,661,120 | 92,033,280 |
| Size | 483.2 MB | 87.8 MB |
| Events in quadrant A | 3,263,621 | 665,386 |
| Events in quadrant B | 8,631,231 | 442,955 |
| Events in quadrant C | 3,190,818 | 635,299 |
| Events in quadrant D | 3,165,789 | 591,952 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14187 | 2 |
| B | 0 | 30059 | 2 |
| C | 0 | 14106 | 2 |
| D | 0 | 14153 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6467 | 44 | 0.680377% |
| B | 6467 | 2591 | 40.064945% |
| C | 6467 | 69 | 1.066955% |
| D | 6467 | 45 | 0.695840% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8932 | 6469 | 17 | 17 | 0.19% | 0.26% |  |
| B | 8932 | 6468 | 1667 | 1667 | 18.66% | 25.77% |  |
| C | 8932 | 6469 | 36 | 36 | 0.40% | 0.56% |  |
| D | 8932 | 6469 | 40 | 40 | 0.45% | 0.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 129477 | 713.96 | 732 | 716 | 180.3 |
| A | 10 | 143 | 86977 | 478.31 | 732 | 716 | 180.3 |
| A | 12 | 114 | 66281 | 363.55 | 732 | 716 | 180.3 |
| B | 2 | 249 | 5542539 | 50660.21 | 511 | 492 | 109.4 |
| B | 5 | 172 | 827037 | 7555.5 | 511 | 492 | 109.4 |
| B | 4 | 201 | 113251 | 1030.74 | 511 | 492 | 109.4 |
| C | 12 | 249 | 99202 | 504.02 | 710 | 704 | 195.4 |
| C | 9 | 237 | 76086 | 385.73 | 710 | 704 | 195.4 |
| C | 14 | 245 | 46785 | 235.8 | 710 | 704 | 195.4 |
| D | 8 | 240 | 87304 | 430.88 | 702 | 672 | 201.1 |
| D | 3 | 12 | 76144 | 375.37 | 702 | 672 | 201.1 |
| D | 0 | 97 | 72760 | 358.54 | 702 | 672 | 201.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
