| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58489cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58489cztM0_level2_quad_clean.evt |
| Size (bytes) | 617,785,920 | 107,611,200 |
| Size | 589.2 MB | 102.6 MB |
| Events in quadrant A | 4,820,373 | 707,401 |
| Events in quadrant B | 9,064,416 | 648,647 |
| Events in quadrant C | 3,939,286 | 706,877 |
| Events in quadrant D | 4,439,983 | 653,375 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19677 | 0 |
| B | 0 | 32381 | 0 |
| C | 0 | 17240 | 0 |
| D | 0 | 18557 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7792 | 401 | 5.146304% |
| B | 7792 | 1674 | 21.483573% |
| C | 7792 | 72 | 0.924025% |
| D | 7793 | 122 | 1.565508% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7792 | 7792 | 311 | 311 | 3.99% | 3.99% |  |
| B | 7792 | 7792 | 1454 | 1454 | 18.66% | 18.66% |  |
| C | 7792 | 7792 | 46 | 46 | 0.59% | 0.59% |  |
| D | 7793 | 7793 | 74 | 74 | 0.95% | 0.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 80 | 996328 | 4771.62 | 845 | 821 | 208.6 |
| A | 10 | 17 | 135511 | 645.59 | 845 | 821 | 208.6 |
| A | 7 | 64 | 135380 | 644.96 | 845 | 821 | 208.6 |
| B | 5 | 172 | 5695348 | 32315.95 | 807 | 775 | 176.2 |
| B | 0 | 245 | 43425 | 242.03 | 807 | 775 | 176.2 |
| B | 2 | 249 | 23590 | 129.47 | 807 | 775 | 176.2 |
| C | 2 | 12 | 205617 | 897.43 | 836 | 831 | 228.2 |
| C | 6 | 223 | 194340 | 848.01 | 836 | 831 | 228.2 |
| C | 12 | 252 | 129702 | 564.75 | 836 | 831 | 228.2 |
| D | 2 | 153 | 829943 | 3548.33 | 828 | 792 | 233.7 |
| D | 2 | 31 | 83444 | 353.71 | 828 | 792 | 233.7 |
| D | 5 | 173 | 66711 | 282.1 | 828 | 792 | 233.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
