| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58495cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58495cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,167,360 | 96,543,360 |
| Size | 467.5 MB | 92.1 MB |
| Events in quadrant A | 3,331,627 | 645,886 |
| Events in quadrant B | 5,028,751 | 651,086 |
| Events in quadrant C | 4,803,783 | 593,074 |
| Events in quadrant D | 4,462,620 | 568,470 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14701 | 2 |
| B | 0 | 19608 | 2 |
| C | 0 | 19081 | 3 |
| D | 0 | 17783 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6661 | 105 | 1.576340% |
| B | 6662 | 549 | 8.240769% |
| C | 6661 | 431 | 6.470500% |
| D | 6661 | 293 | 4.398739% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7661 | 6662 | 56 | 56 | 0.73% | 0.84% |  |
| B | 7662 | 6663 | 360 | 360 | 4.70% | 5.40% |  |
| C | 7661 | 6662 | 360 | 360 | 4.70% | 5.40% |  |
| D | 7661 | 6662 | 211 | 211 | 2.75% | 3.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 201155 | 1091.66 | 737 | 717 | 183.6 |
| A | 10 | 143 | 89931 | 485.89 | 737 | 717 | 183.6 |
| A | 12 | 114 | 42158 | 225.7 | 737 | 717 | 183.6 |
| B | 5 | 172 | 1049823 | 6851.34 | 715 | 691 | 153.1 |
| B | 5 | 185 | 646590 | 4218.03 | 715 | 691 | 153.1 |
| B | 2 | 249 | 112461 | 729.91 | 715 | 691 | 153.1 |
| C | 13 | 3 | 1311390 | 6729.18 | 705 | 699 | 194.8 |
| C | 15 | 223 | 272214 | 1393.98 | 705 | 699 | 194.8 |
| C | 12 | 249 | 120041 | 612.71 | 705 | 699 | 194.8 |
| D | 3 | 12 | 1141253 | 5665.59 | 706 | 675 | 201.3 |
| D | 8 | 240 | 164381 | 813.18 | 706 | 675 | 201.3 |
| D | 2 | 249 | 97874 | 482.82 | 706 | 675 | 201.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
