| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58503cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58503cztM0_level2_quad_clean.evt |
| Size (bytes) | 543,746,880 | 119,992,320 |
| Size | 518.6 MB | 114.4 MB |
| Events in quadrant A | 4,116,004 | 785,555 |
| Events in quadrant B | 4,107,415 | 845,372 |
| Events in quadrant C | 6,177,123 | 729,057 |
| Events in quadrant D | 5,078,332 | 693,328 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18252 | 0 |
| B | 0 | 18116 | 0 |
| C | 0 | 24083 | 0 |
| D | 0 | 21026 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 166 | 0 |
| B | 0 | 166 | 0 |
| C | 0 | 166 | 0 |
| D | 0 | 166 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8350 | 201 | 2.407186% |
| B | 8349 | 270 | 3.233920% |
| C | 8349 | 640 | 7.665589% |
| D | 8349 | 325 | 3.892682% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8350 | 8350 | 78 | 78 | 0.93% | 0.93% |  |
| B | 8349 | 8349 | 12 | 12 | 0.14% | 0.14% |  |
| C | 8349 | 8349 | 462 | 462 | 5.53% | 5.53% |  |
| D | 8349 | 8349 | 244 | 244 | 2.92% | 2.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 249961 | 1045.54 | 962 | 933 | 238.2 |
| A | 4 | 249 | 40342 | 165.46 | 962 | 933 | 238.2 |
| A | 10 | 1 | 32110 | 130.9 | 962 | 933 | 238.2 |
| B | 4 | 171 | 122579 | 581.38 | 955 | 916 | 209.3 |
| B | 0 | 245 | 40511 | 189.21 | 955 | 916 | 209.3 |
| B | 10 | 247 | 36253 | 168.86 | 955 | 916 | 209.3 |
| C | 15 | 157 | 1845150 | 7393.51 | 907 | 897 | 249.4 |
| C | 4 | 5 | 218236 | 871.3 | 907 | 897 | 249.4 |
| C | 5 | 10 | 168671 | 672.6 | 907 | 897 | 249.4 |
| D | 3 | 12 | 991307 | 3870.61 | 916 | 874 | 255.9 |
| D | 2 | 31 | 147850 | 574.38 | 916 | 874 | 255.9 |
| D | 12 | 248 | 130290 | 505.76 | 916 | 874 | 255.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
