| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58514cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58514cztM0_level2_quad_clean.evt |
| Size (bytes) | 419,120,640 | 101,695,680 |
| Size | 399.7 MB | 97.0 MB |
| Events in quadrant A | 3,352,542 | 676,296 |
| Events in quadrant B | 3,813,249 | 716,655 |
| Events in quadrant C | 3,506,770 | 634,635 |
| Events in quadrant D | 4,319,018 | 583,349 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14731 | 2 |
| B | 0 | 15956 | 2 |
| C | 0 | 15389 | 2 |
| D | 0 | 17569 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6722 | 32 | 0.476049% |
| B | 6722 | 208 | 3.094317% |
| C | 6722 | 132 | 1.963701% |
| D | 6722 | 274 | 4.076168% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9137 | 6724 | 9 | 9 | 0.10% | 0.13% |  |
| B | 9137 | 6724 | 114 | 114 | 1.25% | 1.70% |  |
| C | 9137 | 6724 | 111 | 111 | 1.21% | 1.65% |  |
| D | 9137 | 6724 | 234 | 234 | 2.56% | 3.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 218202 | 1146.05 | 764 | 744 | 189.7 |
| A | 10 | 17 | 52473 | 272.62 | 764 | 744 | 189.7 |
| A | 11 | 31 | 33820 | 174.32 | 764 | 744 | 189.7 |
| B | 8 | 234 | 327726 | 2002.53 | 756 | 727 | 163.3 |
| B | 5 | 185 | 155333 | 946.8 | 756 | 727 | 163.3 |
| B | 7 | 252 | 81108 | 492.25 | 756 | 727 | 163.3 |
| C | 4 | 5 | 325649 | 1598.01 | 735 | 727 | 203.3 |
| C | 6 | 13 | 75611 | 368.29 | 735 | 727 | 203.3 |
| C | 12 | 249 | 67236 | 327.1 | 735 | 727 | 203.3 |
| D | 3 | 12 | 1122216 | 5431.89 | 719 | 687 | 206.5 |
| D | 2 | 31 | 102634 | 493.76 | 719 | 687 | 206.5 |
| D | 8 | 240 | 88245 | 424.07 | 719 | 687 | 206.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
