| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58524cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58524cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,390,720 | 96,526,080 |
| Size | 461.0 MB | 92.1 MB |
| Events in quadrant A | 3,951,002 | 644,050 |
| Events in quadrant B | 3,467,354 | 688,845 |
| Events in quadrant C | 5,324,304 | 569,248 |
| Events in quadrant D | 4,637,618 | 559,833 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16189 | 2 |
| B | 0 | 14907 | 2 |
| C | 0 | 20524 | 2 |
| D | 0 | 18262 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6607 | 73 | 1.104889% |
| B | 6607 | 121 | 1.831391% |
| C | 6606 | 676 | 10.233121% |
| D | 6606 | 378 | 5.722071% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7572 | 6607 | 25 | 25 | 0.33% | 0.38% |  |
| B | 7572 | 6607 | 31 | 31 | 0.41% | 0.47% |  |
| C | 7571 | 6606 | 575 | 575 | 7.59% | 8.70% |  |
| D | 7571 | 6606 | 309 | 309 | 4.08% | 4.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 782775 | 4253.32 | 738 | 719 | 183.9 |
| A | 10 | 17 | 102532 | 553.72 | 738 | 719 | 183.9 |
| A | 10 | 251 | 45796 | 245.16 | 738 | 719 | 183.9 |
| B | 4 | 171 | 107362 | 685.81 | 728 | 702 | 155.5 |
| B | 2 | 249 | 75177 | 478.87 | 728 | 702 | 155.5 |
| B | 5 | 185 | 68296 | 434.62 | 728 | 702 | 155.5 |
| C | 5 | 10 | 941036 | 5006.03 | 688 | 684 | 187.8 |
| C | 4 | 5 | 780745 | 4152.71 | 688 | 684 | 187.8 |
| C | 6 | 223 | 304612 | 1617.98 | 688 | 684 | 187.8 |
| D | 3 | 12 | 1245039 | 6257.61 | 702 | 670 | 198.9 |
| D | 2 | 153 | 187626 | 940.15 | 702 | 670 | 198.9 |
| D | 8 | 240 | 183005 | 916.92 | 702 | 670 | 198.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
