| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58528cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58528cztM0_level2_quad_clean.evt |
| Size (bytes) | 473,351,040 | 91,944,000 |
| Size | 451.4 MB | 87.7 MB |
| Events in quadrant A | 3,203,701 | 619,644 |
| Events in quadrant B | 3,519,975 | 666,296 |
| Events in quadrant C | 5,266,925 | 544,244 |
| Events in quadrant D | 5,037,322 | 509,894 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13698 | 2 |
| B | 0 | 14646 | 2 |
| C | 0 | 20110 | 2 |
| D | 0 | 19565 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6356 | 63 | 0.991189% |
| B | 6356 | 116 | 1.825047% |
| C | 6356 | 693 | 10.903084% |
| D | 6357 | 579 | 9.108070% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8971 | 6553 | 16 | 16 | 0.18% | 0.24% |  |
| B | 8971 | 6552 | 34 | 34 | 0.38% | 0.52% |  |
| C | 8971 | 6543 | 606 | 606 | 6.76% | 9.26% |  |
| D | 8972 | 6552 | 549 | 549 | 6.12% | 8.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 245296 | 1369.74 | 718 | 701 | 178.6 |
| A | 10 | 17 | 46945 | 258.97 | 718 | 701 | 178.6 |
| A | 10 | 251 | 26306 | 143.39 | 718 | 701 | 178.6 |
| B | 0 | 171 | 240107 | 1550.71 | 716 | 690 | 154.4 |
| B | 8 | 234 | 182427 | 1177.11 | 716 | 690 | 154.4 |
| B | 2 | 249 | 47978 | 306.28 | 716 | 690 | 154.4 |
| C | 5 | 10 | 1479365 | 7944.14 | 671 | 664 | 186.1 |
| C | 4 | 5 | 694941 | 3729.92 | 671 | 664 | 186.1 |
| C | 12 | 252 | 139624 | 746.55 | 671 | 664 | 186.1 |
| D | 2 | 249 | 1023269 | 5417.41 | 661 | 630 | 188.8 |
| D | 3 | 12 | 401135 | 2121.67 | 661 | 630 | 188.8 |
| D | 2 | 31 | 375122 | 1983.87 | 661 | 630 | 188.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
