| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58541cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58541cztM0_level2_quad_clean.evt |
| Size (bytes) | 415,091,520 | 97,974,720 |
| Size | 395.9 MB | 93.4 MB |
| Events in quadrant A | 3,806,404 | 641,136 |
| Events in quadrant B | 3,696,621 | 693,045 |
| Events in quadrant C | 3,341,599 | 617,679 |
| Events in quadrant D | 4,025,684 | 570,267 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15403 | 2 |
| B | 0 | 15258 | 2 |
| C | 0 | 14445 | 2 |
| D | 0 | 16175 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6366 | 125 | 1.963556% |
| B | 6366 | 135 | 2.120641% |
| C | 6366 | 73 | 1.146717% |
| D | 6366 | 125 | 1.963556% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7606 | 6367 | 88 | 88 | 1.16% | 1.38% |  |
| B | 7606 | 6367 | 58 | 58 | 0.76% | 0.91% |  |
| C | 7606 | 6367 | 55 | 55 | 0.72% | 0.86% |  |
| D | 7606 | 6367 | 130 | 130 | 1.71% | 2.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 466388 | 2619.18 | 712 | 695 | 177.8 |
| A | 3 | 14 | 440774 | 2475.12 | 712 | 695 | 177.8 |
| A | 3 | 244 | 47808 | 264.98 | 712 | 695 | 177.8 |
| B | 0 | 171 | 302914 | 1977.12 | 710 | 685 | 152.9 |
| B | 0 | 186 | 234286 | 1528.17 | 710 | 685 | 152.9 |
| B | 10 | 247 | 51410 | 331.83 | 710 | 685 | 152.9 |
| C | 4 | 5 | 276875 | 1441.05 | 692 | 685 | 191.7 |
| C | 6 | 223 | 117604 | 610.04 | 692 | 685 | 191.7 |
| C | 12 | 252 | 75537 | 390.55 | 692 | 685 | 191.7 |
| D | 3 | 12 | 317536 | 1604.9 | 684 | 654 | 197.4 |
| D | 2 | 153 | 236052 | 1192.21 | 684 | 654 | 197.4 |
| D | 2 | 249 | 194264 | 980.57 | 684 | 654 | 197.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
