| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58545cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58545cztM0_level2_quad_clean.evt |
| Size (bytes) | 567,927,360 | 119,784,960 |
| Size | 541.6 MB | 114.2 MB |
| Events in quadrant A | 5,028,079 | 784,791 |
| Events in quadrant B | 4,603,848 | 845,195 |
| Events in quadrant C | 4,790,977 | 755,197 |
| Events in quadrant D | 5,960,475 | 668,872 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20469 | 2 |
| B | 0 | 19281 | 2 |
| C | 0 | 19965 | 2 |
| D | 0 | 23642 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 170 | 0 |
| B | 0 | 170 | 0 |
| C | 0 | 170 | 0 |
| D | 0 | 170 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8238 | 262 | 3.180384% |
| B | 8239 | 252 | 3.058624% |
| C | 8239 | 208 | 2.524578% |
| D | 8239 | 618 | 7.500910% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9508 | 8240 | 91 | 91 | 0.96% | 1.10% |  |
| B | 9509 | 8241 | 30 | 30 | 0.32% | 0.36% |  |
| C | 9509 | 8241 | 90 | 90 | 0.95% | 1.09% |  |
| D | 9509 | 8241 | 464 | 464 | 4.88% | 5.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 567648 | 2420.08 | 939 | 913 | 234.2 |
| A | 3 | 14 | 398742 | 1698.81 | 939 | 913 | 234.2 |
| A | 12 | 114 | 259452 | 1104.02 | 939 | 913 | 234.2 |
| B | 0 | 171 | 249407 | 1236.78 | 934 | 900 | 200.9 |
| B | 0 | 186 | 173002 | 856.52 | 934 | 900 | 200.9 |
| B | 8 | 234 | 120713 | 596.29 | 934 | 900 | 200.9 |
| C | 12 | 252 | 594487 | 2360.82 | 916 | 907 | 251.4 |
| C | 1 | 12 | 218349 | 864.82 | 916 | 907 | 251.4 |
| C | 14 | 254 | 83160 | 327.14 | 916 | 907 | 251.4 |
| D | 11 | 176 | 866390 | 3443.84 | 879 | 840 | 251.3 |
| D | 8 | 240 | 527622 | 2095.96 | 879 | 840 | 251.3 |
| D | 3 | 12 | 416211 | 1652.67 | 879 | 840 | 251.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
