| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58553cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58553cztM0_level2_quad_clean.evt |
| Size (bytes) | 542,551,680 | 92,822,400 |
| Size | 517.4 MB | 88.5 MB |
| Events in quadrant A | 3,210,074 | 658,092 |
| Events in quadrant B | 6,320,286 | 527,198 |
| Events in quadrant C | 3,534,434 | 622,773 |
| Events in quadrant D | 6,495,431 | 533,145 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14300 | 2 |
| B | 0 | 23528 | 2 |
| C | 0 | 15426 | 2 |
| D | 0 | 23895 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6728 | 93 | 1.382283% |
| B | 6727 | 1813 | 26.951093% |
| C | 6727 | 133 | 1.977107% |
| D | 6727 | 891 | 13.245132% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7668 | 6729 | 18 | 18 | 0.23% | 0.27% |  |
| B | 7667 | 6725 | 660 | 660 | 8.61% | 9.81% |  |
| C | 7667 | 6728 | 71 | 71 | 0.93% | 1.06% |  |
| D | 7667 | 6727 | 760 | 760 | 9.91% | 11.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 245 | 127728 | 675.32 | 760 | 740 | 188.0 |
| A | 10 | 17 | 25119 | 129.64 | 760 | 740 | 188.0 |
| A | 3 | 14 | 18428 | 94.06 | 760 | 740 | 188.0 |
| B | 6 | 255 | 3148750 | 24613.5 | 595 | 574 | 127.9 |
| B | 8 | 234 | 217699 | 1697.56 | 595 | 574 | 127.9 |
| B | 4 | 171 | 200462 | 1562.79 | 595 | 574 | 127.9 |
| C | 12 | 252 | 139962 | 688.91 | 734 | 728 | 202.1 |
| C | 9 | 237 | 139612 | 687.18 | 734 | 728 | 202.1 |
| C | 4 | 5 | 129832 | 638.79 | 734 | 728 | 202.1 |
| D | 2 | 249 | 2306715 | 11586.1 | 702 | 671 | 199.0 |
| D | 8 | 240 | 299563 | 1501.7 | 702 | 671 | 199.0 |
| D | 3 | 12 | 287635 | 1441.77 | 702 | 671 | 199.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
