| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58557cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58557cztM0_level2_quad_clean.evt |
| Size (bytes) | 400,227,840 | 96,523,200 |
| Size | 381.7 MB | 92.1 MB |
| Events in quadrant A | 3,444,198 | 633,595 |
| Events in quadrant B | 3,941,239 | 678,701 |
| Events in quadrant C | 2,898,483 | 610,438 |
| Events in quadrant D | 4,036,103 | 555,520 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14707 | 3 |
| B | 0 | 16095 | 3 |
| C | 0 | 13340 | 3 |
| D | 0 | 16422 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 22 | 0 |
| C | 0 | 22 | 0 |
| D | 0 | 22 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6364 | 56 | 0.879950% |
| B | 6364 | 159 | 2.498429% |
| C | 6364 | 20 | 0.314268% |
| D | 6364 | 187 | 2.938404% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7544 | 6366 | 23 | 23 | 0.30% | 0.36% |  |
| B | 7544 | 6366 | 71 | 71 | 0.94% | 1.12% |  |
| C | 7544 | 6366 | 12 | 12 | 0.16% | 0.19% |  |
| D | 7544 | 6366 | 164 | 164 | 2.17% | 2.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 248 | 484582 | 2766.24 | 705 | 690 | 174.9 |
| A | 10 | 17 | 136603 | 776.97 | 705 | 690 | 174.9 |
| A | 4 | 3 | 22899 | 126.96 | 705 | 690 | 174.9 |
| B | 0 | 171 | 167481 | 1117.72 | 700 | 676 | 149.2 |
| B | 5 | 185 | 151489 | 1010.56 | 700 | 676 | 149.2 |
| B | 8 | 234 | 149361 | 996.3 | 700 | 676 | 149.2 |
| C | 12 | 252 | 49958 | 259.4 | 688 | 683 | 190.0 |
| C | 12 | 249 | 49599 | 257.51 | 688 | 683 | 190.0 |
| C | 6 | 223 | 36248 | 187.22 | 688 | 683 | 190.0 |
| D | 3 | 12 | 480980 | 2495.77 | 671 | 642 | 192.5 |
| D | 2 | 31 | 286849 | 1487.09 | 671 | 642 | 192.5 |
| D | 9 | 102 | 190635 | 987.18 | 671 | 642 | 192.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
