| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58560cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58560cztM0_level2_quad_clean.evt |
| Size (bytes) | 480,522,240 | 110,848,320 |
| Size | 458.3 MB | 105.7 MB |
| Events in quadrant A | 3,696,873 | 716,244 |
| Events in quadrant B | 4,481,893 | 755,973 |
| Events in quadrant C | 3,920,708 | 703,884 |
| Events in quadrant D | 5,087,918 | 643,248 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16645 | 2 |
| B | 0 | 18578 | 2 |
| C | 0 | 17289 | 2 |
| D | 0 | 20723 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7715 | 215 | 2.786779% |
| B | 7715 | 410 | 5.314323% |
| C | 7715 | 105 | 1.360985% |
| D | 7715 | 348 | 4.510693% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7730 | 7716 | 4 | 4 | 0.05% | 0.05% |  |
| B | 7730 | 7716 | 67 | 67 | 0.87% | 0.87% |  |
| C | 7730 | 7716 | 33 | 33 | 0.43% | 0.43% |  |
| D | 7730 | 7716 | 229 | 229 | 2.96% | 2.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 249 | 48147 | 216.79 | 889 | 866 | 218.1 |
| A | 10 | 251 | 41702 | 187.24 | 889 | 866 | 218.1 |
| A | 4 | 3 | 33380 | 149.08 | 889 | 866 | 218.1 |
| B | 0 | 186 | 321407 | 1681.05 | 874 | 840 | 190.7 |
| B | 0 | 171 | 303236 | 1585.76 | 874 | 840 | 190.7 |
| B | 8 | 128 | 74142 | 384.39 | 874 | 840 | 190.7 |
| C | 14 | 245 | 134122 | 554.85 | 864 | 855 | 240.2 |
| C | 6 | 223 | 98267 | 405.57 | 864 | 855 | 240.2 |
| C | 4 | 5 | 75415 | 310.43 | 864 | 855 | 240.2 |
| D | 2 | 249 | 750160 | 3108.84 | 845 | 809 | 241.0 |
| D | 3 | 12 | 659495 | 2732.7 | 845 | 809 | 241.0 |
| D | 2 | 207 | 87682 | 360.41 | 845 | 809 | 241.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
