| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58562cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58562cztM0_level2_quad_clean.evt |
| Size (bytes) | 468,339,840 | 112,824,000 |
| Size | 446.6 MB | 107.6 MB |
| Events in quadrant A | 3,669,165 | 731,424 |
| Events in quadrant B | 4,320,059 | 784,093 |
| Events in quadrant C | 4,113,424 | 702,940 |
| Events in quadrant D | 4,624,951 | 653,240 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16450 | 0 |
| B | 0 | 18214 | 0 |
| C | 0 | 17781 | 0 |
| D | 0 | 19248 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7831 | 102 | 1.302516% |
| B | 7832 | 218 | 2.783453% |
| C | 7832 | 102 | 1.302349% |
| D | 7832 | 203 | 2.591931% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7831 | 7831 | 9 | 9 | 0.11% | 0.11% |  |
| B | 7832 | 7832 | 40 | 40 | 0.51% | 0.51% |  |
| C | 7832 | 7832 | 65 | 65 | 0.83% | 0.83% |  |
| D | 7832 | 7832 | 150 | 150 | 1.92% | 1.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 61823 | 282.65 | 873 | 848 | 215.7 |
| A | 4 | 249 | 61518 | 281.24 | 873 | 848 | 215.7 |
| A | 4 | 3 | 37729 | 170.96 | 873 | 848 | 215.7 |
| B | 8 | 234 | 325300 | 1735.21 | 864 | 832 | 187.0 |
| B | 0 | 171 | 191939 | 1022.01 | 864 | 832 | 187.0 |
| B | 10 | 247 | 93205 | 494.0 | 864 | 832 | 187.0 |
| C | 4 | 5 | 370371 | 1606.13 | 845 | 837 | 230.1 |
| C | 12 | 252 | 218269 | 945.04 | 845 | 837 | 230.1 |
| C | 13 | 3 | 47162 | 201.35 | 845 | 837 | 230.1 |
| D | 2 | 249 | 543703 | 2318.7 | 834 | 796 | 234.1 |
| D | 8 | 240 | 469315 | 2001.0 | 834 | 796 | 234.1 |
| D | 2 | 207 | 102723 | 435.32 | 834 | 796 | 234.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
