| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58580cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58580cztM0_level2_quad_clean.evt |
| Size (bytes) | 449,887,680 | 90,247,680 |
| Size | 429.0 MB | 86.1 MB |
| Events in quadrant A | 4,617,366 | 566,347 |
| Events in quadrant B | 3,842,738 | 635,821 |
| Events in quadrant C | 3,736,611 | 566,693 |
| Events in quadrant D | 3,966,340 | 523,331 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18205 | 1 |
| B | 0 | 15720 | 1 |
| C | 0 | 15613 | 1 |
| D | 0 | 15906 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6308 | 442 | 7.006975% |
| B | 6309 | 206 | 3.265177% |
| C | 6309 | 221 | 3.502932% |
| D | 6309 | 282 | 4.469805% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7053 | 6308 | 315 | 315 | 4.47% | 4.99% |  |
| B | 7054 | 6309 | 61 | 61 | 0.86% | 0.97% |  |
| C | 7054 | 6310 | 140 | 140 | 1.98% | 2.22% |  |
| D | 7054 | 6309 | 207 | 207 | 2.93% | 3.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 1143457 | 6848.73 | 678 | 662 | 166.9 |
| A | 12 | 114 | 426560 | 2552.39 | 678 | 662 | 166.9 |
| A | 13 | 248 | 166956 | 996.59 | 678 | 662 | 166.9 |
| B | 4 | 171 | 341343 | 2324.28 | 684 | 659 | 146.6 |
| B | 0 | 171 | 203095 | 1381.09 | 684 | 659 | 146.6 |
| B | 6 | 255 | 191747 | 1303.67 | 684 | 659 | 146.6 |
| C | 13 | 3 | 578949 | 3114.1 | 674 | 667 | 185.7 |
| C | 12 | 252 | 166449 | 892.75 | 674 | 667 | 185.7 |
| C | 1 | 12 | 126394 | 677.05 | 674 | 667 | 185.7 |
| D | 8 | 240 | 462183 | 2422.0 | 673 | 644 | 190.6 |
| D | 2 | 31 | 275721 | 1443.51 | 673 | 644 | 190.6 |
| D | 3 | 12 | 240081 | 1256.49 | 673 | 644 | 190.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
