| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_044T04_9000006592_58588cztM0_level2.fits | modeM0/AS1A14_044T04_9000006592_58588cztM0_level2_quad_clean.evt |
| Size (bytes) | 504,345,600 | 99,639,360 |
| Size | 481.0 MB | 95.0 MB |
| Events in quadrant A | 4,469,822 | 653,476 |
| Events in quadrant B | 6,072,610 | 641,282 |
| Events in quadrant C | 3,792,700 | 628,869 |
| Events in quadrant D | 3,768,283 | 586,190 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18375 | 2 |
| B | 0 | 23006 | 2 |
| C | 0 | 16522 | 2 |
| D | 0 | 16727 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7282 | 139 | 1.908816% |
| B | 7282 | 842 | 11.562757% |
| C | 7283 | 110 | 1.510367% |
| D | 7283 | 78 | 1.070987% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9233 | 7480 | 46 | 46 | 0.50% | 0.61% |  |
| B | 9233 | 7474 | 519 | 519 | 5.62% | 6.94% |  |
| C | 9234 | 7481 | 64 | 64 | 0.69% | 0.86% |  |
| D | 9234 | 7481 | 29 | 29 | 0.31% | 0.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 1019678 | 5042.57 | 815 | 795 | 202.1 |
| A | 15 | 233 | 100573 | 493.81 | 815 | 795 | 202.1 |
| A | 13 | 248 | 53732 | 261.99 | 815 | 795 | 202.1 |
| B | 5 | 172 | 1363375 | 8169.34 | 779 | 750 | 166.8 |
| B | 6 | 255 | 1025977 | 6146.54 | 779 | 750 | 166.8 |
| B | 0 | 171 | 123724 | 737.27 | 779 | 750 | 166.8 |
| C | 12 | 254 | 290871 | 1328.8 | 795 | 789 | 218.3 |
| C | 12 | 252 | 95408 | 433.43 | 795 | 789 | 218.3 |
| C | 2 | 12 | 87023 | 395.02 | 795 | 789 | 218.3 |
| D | 5 | 38 | 233518 | 1026.92 | 790 | 754 | 226.7 |
| D | 2 | 249 | 121704 | 533.61 | 790 | 754 | 226.7 |
| D | 2 | 120 | 91581 | 400.72 | 790 | 754 | 226.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
