| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T06_9000006594_58632cztM0_level2.fits | modeM0/AS1A14_004T06_9000006594_58632cztM0_level2_quad_clean.evt |
| Size (bytes) | 650,626,560 | 101,160,000 |
| Size | 620.5 MB | 96.5 MB |
| Events in quadrant A | 4,050,728 | 689,918 |
| Events in quadrant B | 3,753,623 | 744,860 |
| Events in quadrant C | 10,434,778 | 499,593 |
| Events in quadrant D | 5,278,534 | 619,731 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17344 | 2 |
| B | 0 | 16393 | 3 |
| C | 0 | 36053 | 2 |
| D | 0 | 20708 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7303 | 233 | 3.190470% |
| B | 7302 | 173 | 2.369214% |
| C | 7303 | 2201 | 30.138299% |
| D | 7303 | 422 | 5.778447% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8688 | 7305 | 87 | 87 | 1.00% | 1.19% |  |
| B | 8687 | 7304 | 47 | 47 | 0.54% | 0.64% |  |
| C | 8688 | 7305 | 2060 | 2060 | 23.71% | 28.20% |  |
| D | 8688 | 7305 | 303 | 303 | 3.49% | 4.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 249 | 730498 | 3640.12 | 800 | 777 | 200.5 |
| A | 12 | 114 | 81263 | 401.49 | 800 | 777 | 200.5 |
| A | 10 | 251 | 55357 | 272.27 | 800 | 777 | 200.5 |
| B | 8 | 128 | 180889 | 1059.42 | 796 | 767 | 170.0 |
| B | 6 | 255 | 118210 | 690.76 | 796 | 767 | 170.0 |
| B | 8 | 234 | 106891 | 624.18 | 796 | 767 | 170.0 |
| C | 15 | 217 | 5389153 | 29199.21 | 676 | 671 | 184.5 |
| C | 15 | 164 | 1453655 | 7873.46 | 676 | 671 | 184.5 |
| C | 12 | 254 | 449056 | 2429.72 | 676 | 671 | 184.5 |
| D | 8 | 240 | 1172893 | 5410.89 | 769 | 735 | 216.6 |
| D | 2 | 249 | 476770 | 2197.46 | 769 | 735 | 216.6 |
| D | 8 | 160 | 169895 | 780.87 | 769 | 735 | 216.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
