| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T06_9000006594_58649cztM0_level2.fits | modeM0/AS1A14_004T06_9000006594_58649cztM0_level2_quad_clean.evt |
| Size (bytes) | 18,506,880 | 1,483,200 |
| Size | 17.6 MB | 1.4 MB |
| Events in quadrant A | 367,397 | 1,106 |
| Events in quadrant B | 73,746 | 8,441 |
| Events in quadrant C | 77,601 | 8,643 |
| Events in quadrant D | 149,043 | 6,367 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1249 | 46 |
| B | 0 | 363 | 13 |
| C | 0 | 375 | 14 |
| D | 0 | 588 | 17 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 172 | 127 | 73.837209% |
| B | 174 | 0 | 0.000000% |
| C | 175 | 0 | 0.000000% |
| D | 175 | 18 | 10.285714% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 173 | 172 | 123 | 123 | 71.10% | 71.51% |  |
| B | 175 | 175 | 0 | 0 | 0.00% | 0.00% |  |
| C | 176 | 176 | 0 | 0 | 0.00% | 0.00% |  |
| D | 175 | 175 | 17 | 17 | 9.71% | 9.71% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 114 | 256413 | 53369.55 | 12 | 12 | 4.8 |
| A | 10 | 17 | 55776 | 11607.21 | 12 | 12 | 4.8 |
| A | 3 | 245 | 2819 | 584.27 | 12 | 12 | 4.8 |
| B | 8 | 234 | 1778 | 314.65 | 17 | 17 | 5.6 |
| B | 5 | 185 | 1182 | 208.16 | 17 | 17 | 5.6 |
| B | 0 | 186 | 695 | 121.14 | 17 | 17 | 5.6 |
| C | 12 | 252 | 6299 | 965.08 | 17 | 16 | 6.5 |
| C | 13 | 3 | 3145 | 480.62 | 17 | 16 | 6.5 |
| C | 12 | 250 | 346 | 50.69 | 17 | 16 | 6.5 |
| D | 8 | 240 | 59422 | 9851.85 | 16 | 15 | 6.0 |
| D | 11 | 129 | 16615 | 2752.89 | 16 | 15 | 6.0 |
| D | 2 | 249 | 6329 | 1047.09 | 16 | 15 | 6.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
