| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T06_9000006594_58672cztM0_level2.fits | modeM0/AS1A14_004T06_9000006594_58672cztM0_level2_quad_clean.evt |
| Size (bytes) | 450,576,000 | 97,099,200 |
| Size | 429.7 MB | 92.6 MB |
| Events in quadrant A | 4,005,537 | 630,550 |
| Events in quadrant B | 3,505,207 | 688,817 |
| Events in quadrant C | 3,140,329 | 625,769 |
| Events in quadrant D | 5,541,190 | 558,096 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16527 | 44 |
| B | 0 | 14754 | 53 |
| C | 0 | 13712 | 40 |
| D | 0 | 20831 | 90 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6260 | 375 | 5.990415% |
| B | 6261 | 153 | 2.443699% |
| C | 6262 | 120 | 1.916321% |
| D | 6252 | 549 | 8.781190% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7400 | 6268 | 249 | 249 | 3.36% | 3.97% |  |
| B | 7405 | 6269 | 19 | 19 | 0.26% | 0.30% |  |
| C | 7408 | 6272 | 42 | 42 | 0.57% | 0.67% |  |
| D | 7396 | 6260 | 505 | 505 | 6.83% | 8.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 17 | 563341 | 3198.99 | 712 | 694 | 175.9 |
| A | 4 | 249 | 547621 | 3109.61 | 712 | 694 | 175.9 |
| A | 10 | 251 | 91229 | 514.75 | 712 | 694 | 175.9 |
| B | 2 | 249 | 182351 | 1210.77 | 705 | 678 | 150.0 |
| B | 8 | 234 | 150053 | 995.52 | 705 | 678 | 150.0 |
| B | 0 | 171 | 142358 | 944.24 | 705 | 678 | 150.0 |
| C | 14 | 254 | 170482 | 875.67 | 706 | 697 | 193.9 |
| C | 12 | 254 | 64907 | 331.17 | 706 | 697 | 193.9 |
| C | 15 | 147 | 47703 | 242.44 | 706 | 697 | 193.9 |
| D | 2 | 249 | 1355177 | 6959.03 | 686 | 653 | 194.6 |
| D | 8 | 240 | 749102 | 3845.25 | 686 | 653 | 194.6 |
| D | 8 | 160 | 369132 | 1893.11 | 686 | 653 | 194.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
