| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_106T01_9000006596_58807cztM0_level2.fits | modeM0/AS1A14_106T01_9000006596_58807cztM0_level2_quad_clean.evt |
| Size (bytes) | 615,686,400 | 97,384,320 |
| Size | 587.2 MB | 92.9 MB |
| Events in quadrant A | 3,523,398 | 680,261 |
| Events in quadrant B | 4,529,781 | 705,295 |
| Events in quadrant C | 5,035,409 | 580,601 |
| Events in quadrant D | 9,161,061 | 496,424 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15375 | 0 |
| B | 0 | 18386 | 0 |
| C | 0 | 19940 | 0 |
| D | 0 | 32194 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6980 | 74 | 1.060172% |
| B | 6979 | 374 | 5.358934% |
| C | 6979 | 824 | 11.806849% |
| D | 6979 | 1557 | 22.309787% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6980 | 6980 | 30 | 30 | 0.43% | 0.43% |  |
| B | 6979 | 6979 | 195 | 195 | 2.79% | 2.79% |  |
| C | 6979 | 6979 | 422 | 422 | 6.05% | 6.05% |  |
| D | 6978 | 6978 | 1401 | 1401 | 20.08% | 20.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 210866 | 1068.32 | 789 | 768 | 196.7 |
| A | 15 | 233 | 73035 | 367.47 | 789 | 768 | 196.7 |
| A | 2 | 143 | 56910 | 285.47 | 789 | 768 | 196.7 |
| B | 2 | 136 | 492948 | 2938.25 | 771 | 739 | 167.5 |
| B | 4 | 171 | 208940 | 1242.86 | 771 | 739 | 167.5 |
| B | 8 | 128 | 200813 | 1194.35 | 771 | 739 | 167.5 |
| C | 15 | 198 | 1445086 | 7360.1 | 708 | 702 | 196.2 |
| C | 13 | 3 | 314426 | 1598.63 | 708 | 702 | 196.2 |
| C | 12 | 252 | 253030 | 1285.78 | 708 | 702 | 196.2 |
| D | 12 | 110 | 3887348 | 19265.53 | 705 | 675 | 201.7 |
| D | 11 | 129 | 1431826 | 7093.95 | 705 | 675 | 201.7 |
| D | 2 | 249 | 467343 | 2313.19 | 705 | 675 | 201.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
