| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T07_9000006598_58909cztM0_level2.fits | modeM0/AS1A14_004T07_9000006598_58909cztM0_level2_quad_clean.evt |
| Size (bytes) | 864,999,360 | 92,180,160 |
| Size | 824.9 MB | 87.9 MB |
| Events in quadrant A | 7,297,978 | 637,647 |
| Events in quadrant B | 4,677,292 | 739,556 |
| Events in quadrant C | 3,960,687 | 680,390 |
| Events in quadrant D | 15,521,221 | 227,686 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26564 | 0 |
| B | 0 | 18818 | 0 |
| C | 0 | 16962 | 0 |
| D | 0 | 51107 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7256 | 1037 | 14.291621% |
| B | 7257 | 404 | 5.567039% |
| C | 7257 | 131 | 1.805154% |
| D | 7257 | 5133 | 70.731707% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7256 | 7256 | 767 | 767 | 10.57% | 10.57% |  |
| B | 7257 | 7257 | 193 | 193 | 2.66% | 2.66% |  |
| C | 7257 | 7257 | 93 | 93 | 1.28% | 1.28% |  |
| D | 7257 | 7257 | 4707 | 4707 | 64.86% | 64.86% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 3847165 | 19584.21 | 793 | 773 | 196.4 |
| A | 15 | 233 | 98526 | 497.72 | 793 | 773 | 196.4 |
| A | 5 | 113 | 71562 | 360.43 | 793 | 773 | 196.4 |
| B | 4 | 236 | 410462 | 2363.31 | 804 | 775 | 173.4 |
| B | 4 | 171 | 375906 | 2163.97 | 804 | 775 | 173.4 |
| B | 5 | 185 | 135468 | 776.99 | 804 | 775 | 173.4 |
| C | 12 | 252 | 367757 | 1663.47 | 803 | 797 | 220.6 |
| C | 6 | 13 | 167953 | 757.73 | 803 | 797 | 220.6 |
| C | 15 | 208 | 74996 | 336.35 | 803 | 797 | 220.6 |
| D | 12 | 110 | 12909880 | 81569.89 | 558 | 533 | 158.3 |
| D | 8 | 160 | 117556 | 739.43 | 558 | 533 | 158.3 |
| D | 2 | 249 | 64670 | 405.26 | 558 | 533 | 158.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
