| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T02_9000006600_59012cztM0_level2.fits | modeM0/AS1A14_004T02_9000006600_59012cztM0_level2_quad_clean.evt |
| Size (bytes) | 952,968,960 | 84,444,480 |
| Size | 908.8 MB | 80.5 MB |
| Events in quadrant A | 4,161,241 | 716,665 |
| Events in quadrant B | 5,880,052 | 711,566 |
| Events in quadrant C | 18,317,648 | 364 |
| Events in quadrant D | 6,344,871 | 614,574 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17359 | 0 |
| B | 0 | 22504 | 1 |
| C | 0 | 59129 | 0 |
| D | 0 | 23846 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7375 | 127 | 1.722034% |
| B | 7374 | 730 | 9.899647% |
| C | 7374 | 7372 | 99.972878% |
| D | 7374 | 493 | 6.685652% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7375 | 7375 | 79 | 79 | 1.07% | 1.07% |  |
| B | 7374 | 7374 | 414 | 414 | 5.61% | 5.61% |  |
| C | 7373 | 7373 | 7292 | 7292 | 98.90% | 98.90% |  |
| D | 7374 | 7374 | 449 | 449 | 6.09% | 6.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 715334 | 3488.02 | 829 | 810 | 204.9 |
| A | 15 | 233 | 60939 | 293.53 | 829 | 810 | 204.9 |
| A | 3 | 14 | 58851 | 283.33 | 829 | 810 | 204.9 |
| B | 2 | 249 | 1664474 | 9770.63 | 789 | 761 | 170.3 |
| B | 12 | 17 | 436275 | 2557.68 | 789 | 761 | 170.3 |
| B | 3 | 238 | 166772 | 974.95 | 789 | 761 | 170.3 |
| C | 15 | 219 | 17041651 | 252349.96 | 245 | 243 | 67.5 |
| C | 12 | 252 | 249073 | 3684.69 | 245 | 243 | 67.5 |
| C | 14 | 254 | 36541 | 537.5 | 245 | 243 | 67.5 |
| D | 12 | 110 | 1664021 | 7595.23 | 786 | 755 | 219.0 |
| D | 11 | 129 | 497031 | 2266.22 | 786 | 755 | 219.0 |
| D | 8 | 160 | 447208 | 2038.71 | 786 | 755 | 219.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
