| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T02_9000006600_59055cztM0_level2.fits | modeM0/AS1A14_004T02_9000006600_59055cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,032,160,320 | 85,469,760 |
| Size | 984.3 MB | 81.5 MB |
| Events in quadrant A | 3,750,188 | 750,651 |
| Events in quadrant B | 4,047,941 | 791,961 |
| Events in quadrant C | 10,549,486 | 502,384 |
| Events in quadrant D | 19,256,798 | 2,530 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16430 | 0 |
| B | 0 | 17436 | 0 |
| C | 0 | 36807 | 0 |
| D | 0 | 62518 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7772 | 44 | 0.566135% |
| B | 7772 | 173 | 2.225939% |
| C | 7772 | 2569 | 33.054555% |
| D | 7772 | 7751 | 99.729799% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7772 | 7772 | 27 | 27 | 0.35% | 0.35% |  |
| B | 7772 | 7772 | 106 | 106 | 1.36% | 1.36% |  |
| C | 7772 | 7772 | 1457 | 1457 | 18.75% | 18.75% |  |
| D | 7771 | 7771 | 6810 | 6810 | 87.63% | 87.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 134124 | 621.32 | 868 | 846 | 214.5 |
| A | 10 | 251 | 88800 | 410.03 | 868 | 846 | 214.5 |
| A | 3 | 14 | 54091 | 248.22 | 868 | 846 | 214.5 |
| B | 4 | 236 | 389369 | 2145.03 | 850 | 819 | 181.1 |
| B | 2 | 249 | 68771 | 375.14 | 850 | 819 | 181.1 |
| B | 5 | 185 | 60826 | 331.28 | 850 | 819 | 181.1 |
| C | 15 | 219 | 3616802 | 19875.44 | 664 | 658 | 181.9 |
| C | 15 | 198 | 3127190 | 17184.38 | 664 | 658 | 181.9 |
| C | 2 | 12 | 485987 | 2667.52 | 664 | 658 | 181.9 |
| D | 12 | 1 | 18567785 | 558101.39 | 112 | 106 | 33.3 |
| D | 6 | 239 | 77095 | 2314.11 | 112 | 106 | 33.3 |
| D | 2 | 62 | 72725 | 2182.76 | 112 | 106 | 33.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
