| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T02_9000006600_59056cztM0_level2.fits | modeM0/AS1A14_004T02_9000006600_59056cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,030,893,120 | 68,546,880 |
| Size | 983.1 MB | 65.4 MB |
| Events in quadrant A | 3,886,927 | 685,870 |
| Events in quadrant B | 4,241,986 | 704,547 |
| Events in quadrant C | 13,247,850 | 184,449 |
| Events in quadrant D | 16,231,652 | 5,305 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16473 | 0 |
| B | 0 | 17538 | 0 |
| C | 0 | 44235 | 0 |
| D | 0 | 53058 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7111 | 191 | 2.685979% |
| B | 7112 | 416 | 5.849269% |
| C | 7112 | 5158 | 72.525309% |
| D | 7111 | 7064 | 99.339052% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7111 | 7111 | 137 | 137 | 1.93% | 1.93% |  |
| B | 7112 | 7112 | 193 | 193 | 2.71% | 2.71% |  |
| C | 7112 | 7112 | 3542 | 3542 | 49.80% | 49.80% |  |
| D | 7110 | 7110 | 5307 | 5307 | 74.64% | 74.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 10 | 251 | 365032 | 1841.05 | 800 | 779 | 197.9 |
| A | 15 | 233 | 180522 | 908.48 | 800 | 779 | 197.9 |
| A | 14 | 238 | 125311 | 629.42 | 800 | 779 | 197.9 |
| B | 2 | 249 | 560699 | 3357.71 | 776 | 747 | 166.8 |
| B | 4 | 236 | 243480 | 1455.53 | 776 | 747 | 166.8 |
| B | 0 | 186 | 64079 | 379.77 | 776 | 747 | 166.8 |
| C | 15 | 198 | 8391431 | 85568.0 | 353 | 351 | 98.1 |
| C | 15 | 219 | 2058937 | 20992.42 | 353 | 351 | 98.1 |
| C | 14 | 254 | 726424 | 7404.13 | 353 | 351 | 98.1 |
| D | 12 | 1 | 15582357 | 528608.6 | 98 | 94 | 29.5 |
| D | 6 | 239 | 98072 | 3323.78 | 98 | 94 | 29.5 |
| D | 2 | 252 | 78988 | 2676.38 | 98 | 94 | 29.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
