| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T02_9000006600_59070cztM0_level2.fits | modeM0/AS1A14_004T02_9000006600_59070cztM0_level2_quad_clean.evt |
| Size (bytes) | 974,836,800 | 77,109,120 |
| Size | 929.7 MB | 73.5 MB |
| Events in quadrant A | 6,860,393 | 587,079 |
| Events in quadrant B | 3,670,528 | 716,413 |
| Events in quadrant C | 6,767,507 | 495,287 |
| Events in quadrant D | 18,240,864 | 45,216 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25205 | 0 |
| B | 0 | 15797 | 0 |
| C | 0 | 25003 | 0 |
| D | 0 | 58812 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7043 | 1109 | 15.746131% |
| B | 7044 | 154 | 2.186258% |
| C | 7044 | 1847 | 26.220897% |
| D | 7043 | 6585 | 93.497089% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7042 | 7042 | 955 | 955 | 13.56% | 13.56% |  |
| B | 7044 | 7044 | 64 | 64 | 0.91% | 0.91% |  |
| C | 7044 | 7044 | 668 | 668 | 9.48% | 9.48% |  |
| D | 7043 | 7043 | 6518 | 6518 | 92.55% | 92.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 64 | 3551238 | 19647.92 | 730 | 711 | 180.7 |
| A | 0 | 24 | 256985 | 1418.17 | 730 | 711 | 180.7 |
| A | 10 | 251 | 68885 | 377.26 | 730 | 711 | 180.7 |
| B | 4 | 171 | 266099 | 1611.89 | 768 | 739 | 164.6 |
| B | 0 | 157 | 88073 | 530.5 | 768 | 739 | 164.6 |
| B | 5 | 185 | 85004 | 511.85 | 768 | 739 | 164.6 |
| C | 15 | 198 | 3091768 | 16781.11 | 674 | 668 | 184.2 |
| C | 12 | 252 | 704138 | 3819.03 | 674 | 668 | 184.2 |
| C | 6 | 223 | 134638 | 727.3 | 674 | 668 | 184.2 |
| D | 12 | 1 | 16302101 | 281015.47 | 199 | 189 | 58.0 |
| D | 2 | 62 | 517798 | 8922.64 | 199 | 189 | 58.0 |
| D | 6 | 239 | 506911 | 8734.97 | 199 | 189 | 58.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
