| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A14_004T02_9000006600_59114cztM0_level2.fits | modeM0/AS1A14_004T02_9000006600_59114cztM0_level2_quad_clean.evt |
| Size (bytes) | 906,073,920 | 96,053,760 |
| Size | 864.1 MB | 91.6 MB |
| Events in quadrant A | 4,624,695 | 764,603 |
| Events in quadrant B | 4,200,581 | 824,205 |
| Events in quadrant C | 6,805,637 | 722,017 |
| Events in quadrant D | 17,281,311 | 35,948 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19506 | 0 |
| B | 0 | 18009 | 0 |
| C | 0 | 25829 | 0 |
| D | 0 | 56900 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 8074 | 156 | 1.932128% |
| B | 8075 | 127 | 1.572755% |
| C | 8075 | 263 | 3.256966% |
| D | 8075 | 7713 | 95.517028% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8074 | 8074 | 56 | 56 | 0.69% | 0.69% |  |
| B | 8074 | 8074 | 63 | 63 | 0.78% | 0.78% |  |
| C | 8074 | 8074 | 182 | 182 | 2.25% | 2.25% |  |
| D | 8074 | 8074 | 5106 | 5106 | 63.24% | 63.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 3 | 14 | 453729 | 2055.3 | 894 | 870 | 220.3 |
| A | 3 | 95 | 408720 | 1851.03 | 894 | 870 | 220.3 |
| A | 10 | 251 | 239495 | 1083.0 | 894 | 870 | 220.3 |
| B | 4 | 236 | 346750 | 1822.1 | 887 | 856 | 189.8 |
| B | 6 | 255 | 93553 | 488.31 | 887 | 856 | 189.8 |
| B | 5 | 185 | 79664 | 415.15 | 887 | 856 | 189.8 |
| C | 3 | 233 | 2796561 | 11842.64 | 859 | 850 | 236.1 |
| C | 12 | 252 | 327563 | 1383.96 | 859 | 850 | 236.1 |
| C | 5 | 250 | 156377 | 658.81 | 859 | 850 | 236.1 |
| D | 12 | 1 | 16109726 | 451680.49 | 121 | 116 | 35.7 |
| D | 12 | 110 | 609534 | 17086.83 | 121 | 116 | 35.7 |
| D | 2 | 249 | 14830 | 412.55 | 121 | 116 | 35.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
| Parameter | TCT0 | TCT_healed |
|---|---|---|
| Tct |  |  |
